Description
Specifications
Performance
- Type: IP security camera
- Placement supported: Indoor
- Connectivity technology: Wired
- PTZ control: Yes
- Certification: EN55032:2012 EN55022:2010; EN55024:2010; EN50121-4:2015 EN61000-6-1:2007; EN61000-6-2:2005 EN61000-6-3:2007+A1:2011 EN61000-6-4:
Design
- Form factor: Dome
- Mounting type: Ceiling
- Product colour: White
- International Protection (IP) code: IP20
- IK code: IK06
Camera
- Minimum illumination: 0.005 lx
- Lens viewing angle, horizontal: 180°
- Lens viewing angle, vertical: 180°
Image sensor
- Number of sensors: 1
- Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
- Progressive scan: Yes
- Sensor type: CMOS
Lens system
- Zoom capability: Yes
- Number of lenses: 1
- Maximum aperture number: 2
- Fixed focal length: 1.6 mm
Video
- Maximum resolution: 3072 x 2048 pixels
- Total megapixels: 6 MP
- Video compression formats: H.264, M-JPEG, MxPEG
- Supported graphics resolutions: 1280 x 720 (HD 720), 1280 x 960, 2048 x 1536 (QXGA), 2592 x 1944, 3072 x 2048
- Video streaming: Yes
Audio
- Built-in speaker(s): Yes
- Sample rate: 16 kHz
- Built-in microphone: Yes
- Voice codecs: G.711, G.722
Network
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet
- Networking standards: IEEE 802.3af
- Supported network protocols: IPv4, IPv6, HTTP, HTTPS, FTP, FTPS, RTP, RTSP, UDP, SNMP, SMTP, DHCP, NTP, SIP
- Wi-Fi: No
- Bluetooth: No
- Cabling technology: 10/100Base-T(X)
- Streaming method: Multicast
Storage
- Built-in HDD: No
- Card reader integrated: Yes
- Compatible memory cards: MicroSD (TransFlash)
- Flash memory: 512 MB
- Internal memory: 1024 MB
Ports & interfaces
- USB port: Yes
- Interface: RJ-45
Security
- Temperature sensor: Yes
Management features
- Web-based management: Yes
Power
- Power source type: PoE
- Power consumption (typical): 5 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
- Height: 51 mm
- Diameter: 12 cm
- Weight: 212 g
Packaging content
- Number of cameras: 1
- Cables included: LAN (RJ-45)
- Mounting kit: Yes
- Quick installation guide: Yes
Logistics data
- Harmonized System (HS) code: 85258900
