  • Type: IP security camera
  • Placement supported: Outdoor
  • Connectivity technology: Wired
  • Maximum operating distance: 107 m
  • Wide Dynamic Range (WDR): Yes
  • Day/night mode: Yes
  • Infrared (IR) cut-off filter: Yes
  • Remote viewing: Yes
  • Dynamic range: 120 dB

Design


  • Form factor: Dome
  • Mounting type: Ceiling
  • Product colour: White
  • Housing material: Metal
  • Protection features: Waterproof
  • International Protection (IP) code: IP67
  • IK code: IK10
  • Weatherproof: Yes

Camera


  • Minimum illumination: 0 lx
  • Lens viewing angle, horizontal: 88°
  • Lens viewing angle, vertical: 46°
  • Lens viewing angle, diagonal: 105.4°
  • Tilt angle range: 0 - 75°
  • Camera shutter speed: 1/3 to 1/10000

Image sensor


  • Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
  • Progressive scan: Yes
  • Sensor type: CMOS

Lens system


  • Detect distance: 107 m
  • Observe distance: 44 m
  • Recognize distance: 21 m
  • Fixed focus: Yes
  • Maximum aperture number: 1.6
  • Identify distance: 11 m
  • Fixed focal length: 4 mm

Night vision


  • Night vision: Yes
  • LED type: IR/White

Video


  • Maximum resolution: 3840 x 2160 pixels
  • Total megapixels: 8 MP
  • Video compression formats: H.264, H.264+, H.265, H.265+
  • Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520, 3840 x 2160
  • Video recording: Yes
  • Image quality adjustment: Brightness, Contrast, Mirror, Saturation, Sharpness
  • Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
  • Bit rate: Main Stream: 256 Kbps to 8 Mbps, Sub-Stream: 64 Kbps to 512 Kbps
  • Back Light Compensation (BLC): Yes
  • Highlight Compensation (HLC): Yes
  • Digital Wide Dynamic Range (DWDR): Yes

Audio


  • Built-in speaker(s): Yes
  • Audio system: 2-way
  • Audio input channels: 1.0 channels
  • Audio output channels: 1.0 channels
  • Audio formats supported: G.711 A-law
  • Sample rate: 8 kHz
  • Built-in microphone: Yes
  • Number of microphones: 1
  • Bit rate range: 0 - 64 Kbit/s

Network


  • Ethernet LAN: Yes
  • Networking standards: IEEE 802.3af, IEEE 802.3at
  • Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
  • Wi-Fi: No
  • Bluetooth: No
  • Live view: Yes

Storage


  • Compatible memory cards: MicroSD (TransFlash)
  • Maximum memory card size: 512 GB

Ports & interfaces


  • Ethernet LAN (RJ-45) ports: 1
  • DC-in jack: Yes

Security


  • Built-in siren: Yes
  • Password protection: Yes
  • Video motion detection: Yes
  • IP address filtering: Yes
  • HTTPS encryption: Yes
  • Detection distance: 107 m
  • Alert notification type: Push notification
  • Intelligent Video Surveillance (IVS) system features: Abnormal sound detection, Crossing line, Human detection, Intrusion, Line crossing detection, Moving object, Region entrance det
  • Motion sensor: Yes
  • Mirror: Yes
  • Human and vehicle targets classification: Yes
  • Digest authentication: Yes

Management features


  • Web-based management: Yes
  • Web browser: Yes
  • Cloud-managed: Yes
  • Reset button: Yes

Power


  • Power source type: DC, PoE
  • Power consumption (max): 11 W
  • Power consumption (Power over Ethernet (PoE)): 12.3 W
  • DC output voltage: 12

Operational conditions


  • Operating temperature (T-T): -30 - 60 °C
  • Storage temperature (T-T): -40 - 60 °C
  • Operating relative humidity (H-H): 0 - 95%
  • Storage relative humidity (H-H): 0 - 95%

Weight & dimensions


  • Width: 122 mm
  • Depth: 122 mm
  • Height: 89 mm
  • Weight: 620 g

Packaging content


  • Number of cameras: 1
  • Manual: Yes
