Description

Specifications

Power


  • Total power: 650 W
  • AC input voltage: 200 - 240 V
  • AC input frequency: 50/60 Hz
  • Input current: 7 A
  • Power Factor Correction (PFC) type: Active
  • Combined power (+3.3V): 180 W
  • Combined power (+12V): 456 W
  • Combined power (+5V): 180 W
  • Combined power (-12V): 6 W
  • Combined power (+5Vsb): 12.5 W
  • Max output current (+3.3V): 25 A
  • Max output current (+12V): 38 A
  • Max output current (+5V): 27 A
  • Max output current (-12V): 0.5 A
  • Max output current (+5Vsb): 2.5 A
  • Efficiency: 85%
  • Power protection features: Over power, Over voltage, Short circuit, Under voltage

Ports & interfaces


  • Motherboard power connector: 20+4 pin ATX
  • Number of SATA power connectors: 4
  • Peripheral (Molex) power connectors (4-pin): 2
  • PCI Express power connectors (6+2 pin): 1
  • Cabling type: Non-Modular

Performance


  • 80 PLUS certification: No
  • Purpose: PC
  • Power supply unit (PSU) form factor: ATX
  • Noise level: 14 dB

Design


  • Product colour: Black
  • Fan diameter: 12 cm

Certificates


  • Compliance certificates: CE, RoHS

Weight & dimensions


  • Width: 150 mm
  • Depth: 145 mm
  • Height: 85 mm
  • Weight: 1.4 kg

Packaging data


  • Package width: 125 mm
  • Package depth: 238 mm
  • Package height: 205 mm
  • Package weight: 1.55 kg
  • Package type: Box
