Description
Specifications
Performance
- Type: Network transmitter & receiver
- Maximum transfer distance: 100 m
- Data transfer rate: 480 Mbit/s
- Cable types supported: Cat6a
- Chipset (transmitter): VS6320
- Plug and Play: Yes
Ports & interfaces
- RJ-45 ports quantity (receiver): 1
- USB Type-C ports quantity (transmitter): 3
- USB Type-C ports quantity (receiver): 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 5
- DC-in jack: Yes
- Contact material: Phosphor bronze
- Connector contacts plating: Gold
- Connector material: Gold
- Ethernet LAN (RJ-45) ports: 2
- RJ-45 ports quantity (transmitter): 1
Design
- Product colour: Black
- Housing material: Metal
- LED indicators: Yes
- Certification: CE, UKCA, FCC, RoHS & REACH, CP65
Power
- External power adapter: Yes
- Output voltage: 24 V
- Output current: 3.75 A
- Power over Ethernet (PoE): Yes
- Power note: 5.5/2.1mm DC
- Included power plug types: AU, EU, UK, US
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage relative humidity (H-H): 10 - 90%
Weight & dimensions
- Width: 140 mm
- Depth: 75 mm
- Height: 23 mm
- Weight: 1.72 kg
Packaging content
- Cables included: USB Type-A to USB Type-B
- Manual: Yes
Packaging data
- Package type: Box
- Package width: 270 mm
- Package depth: 245 mm
- Package height: 75 mm
- Package volume: 2020 cm³
Certificates
- Compliance certificates: CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA
Logistics data
- Harmonized System (HS) code: 85176990
