Description
Specifications
Performance
- Type: IP security camera
- Connectivity technology: Wired
- PTZ control: Yes
- Certification: CE, FCC, IK08
Design
- Form factor: Dome
- Mounting type: Ceiling/wall
- Product colour: Black, White
- LED indicators: Power
- Protection features: Vandal proof
- Country of origin: Taiwan
Camera
- Minimum illumination: 0.1 lx
- Lens viewing angle, horizontal: 83.3°
- White balance: Auto
- Camera shutter type: Electronic
- Camera shutter speed: 1/5 - 1/10000 s
Image sensor
- Optical sensor size: 25.4 / 3.2 mm (1 / 3.2")
- Progressive scan: Yes
- Sensor type: CMOS
Lens system
- Zoom capability: Yes
- Number of lenses: 1
- Fixed focus: Yes
- Focus adjustment: 2.0
- Fixed focal length: 2.93 mm
Night vision
- Night vision: No
Video
- Maximum resolution: 2048 x 1536 pixels
- Total megapixels: 3 MP
- Video formats supported: RAW
- Video compression formats: H.264, M-JPEG
- Supported graphics resolutions: 320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA)
- Supported video modes: 240p, 480p, 720p, 1080p
- Frame rate: 30 fps
- Video streaming: Yes
- Noise reduction: Yes
- Automatic gain control: Yes
- Full HD: Yes
- Image quality adjustment: Brightness, Contrast, Saturation, Sharpness
- Back Light Compensation (BLC): Yes
Audio
- Built-in microphone: No
- Voice codecs: G.711
Network
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet
- Supported network protocols: TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
- Wi-Fi: No
- Bluetooth: No
Storage
- Built-in HDD: No
- Card reader integrated: Yes
- Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
- Maximum memory card size: 64 GB
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 1
- Interface: RJ-45
Management features
- Reset button: Yes
Power
- Power source type: PoE
- Power consumption (typical): 2.91 W
- Power over Ethernet (PoE): Yes
Operational conditions
- Operating temperature (T-T): -10 - 50 °C
- Operating relative humidity (H-H): 10 - 85%
System requirements
- Windows operating systems supported: Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows
Weight & dimensions
- Width: 110 mm
- Depth: 58 mm
- Height: 110 mm
- Weight: 201 g
Packaging data
- Package width: 169 mm
- Package depth: 169 mm
- Package height: 112 mm
- Package weight: 199 g
Sustainability
- Compliance certificates: RoHS
Packaging content
- Number of cameras: 1
- Screws included: Yes
- Quick installation guide: Yes
- Resource CD: Yes
Technical details
- Back light compensation method: Yes
- Iris: Yes
- Number of video streams: 2
Logistics data
- Harmonized System (HS) code: 85258900
- Master (outer) case width: 350 mm
- Master (outer) case length: 350 mm
- Master (outer) case height: 342 mm
- Master (outer) case gross weight: 5.7 kg
- Products per master (outer) case: 12 pc(s)
