Name: LevelOne Hilbert 5-Port Industrial Gigabit PoE Smart Lite Switch, 4 PoE Outputs, 802.3at/af PoE
Brand: LEVELONE
Price: 134 EUR
Availability: InStock

LevelOne Hilbert 5-Port Industrial Gigabit PoE Smart Lite Switch, 4 PoE Outputs, 802.3at/af PoE

134.00 €

110.74 € without VAT

Amount

Brand: LEVELONE

SKU: 117843 PRC: 603603 EAN: 4015867236154 PN: IGS-2105P

Description

Specifications

Management features

Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Web-based management: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 5
Uplink ports quantity: 1

Network

Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802
10G support: No
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring: Yes
Full duplex: Yes
Half duplex: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Auto MDI/MDI-X: Yes
Spanning tree protocol: Yes
Auto-negotiation: Yes
MAC address auto-learning supported: Yes
MAC address auto-aging supported: Yes
VLAN support: Yes
Virtual LAN features: Port-based VLAN
Number of VLANs: 32

Data transmission

Switching capacity: 10 Gbit/s
Forwarding rate: 7.44 Mpps
MAC address table: 2000 entries
Jumbo frames support: Yes
Jumbo frames: 9000
Packet buffer memory: 1.5 MB

Security

IGMP snooping: Yes
Queue scheduling algorithms: Priority queuing (PQ)

Multicast features

Multicast support: Yes

Design

LED indicators: Activity, Link, Power
Redundant fans support: Yes
International Protection (IP) code: IP30
DIN rail mounting: Yes

Performance

Flash memory: 2 MB
Noise level: 0 dB
Fanless: Yes
Mean time between failures (MTBF): 43800 h

Power

Power source: DC/PoE
Power supply included: No
Redundant power supply (RPS) support: Yes
DC input voltage: 44 - 57 V
Power consumption (typical): 68 W
Surge protection: Yes
Surge protection voltage: 4 kV

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 4
Total Power over Ethernet (PoE) budget: 60 W

Operational conditions

Operating temperature (T-T): -40 - 70 °C
Storage temperature (T-T): -40 - 85 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%
Heat dissipation: 23.88 BTU/h

Weight & dimensions

Width: 136 mm
Depth: 108 mm
Height: 38.5 mm
Weight: 450 g

Packaging content

Quick start guide: Yes

Packaging data

Package type: Box
DIN rail included: Yes
Package width: 191 mm
Package depth: 135 mm
Package height: 60 mm
Package weight: 680 g
Terminal block included: Yes

Sustainability

Sustainability compliance: Yes

Technical details

Layers per pallet (air): 16 pc(s)
Pallet gross length: 80 cm
Pallet gross width: 120 cm

Certificates

Compliance certificates: CE, Federal Communications Commission (FCC), RoHS, UKCA

Logistics data

Pallet gross height: 154.4 cm
Country of origin: China
Master (outer) case width: 480 mm
Master (outer) case length: 395 mm
Master (outer) case height: 350 mm
Harmonized System (HS) code: 8517620090
Master (outer) case gross weight: 24 kg
Products per master (outer) case: 34 pc(s)
