LevelOne AC750 Dual Band PoE Wireless Access Point, Ceiling Mount, Controller Managed

$116.17
$116.17 without VAT

More info

Brand: LEVELONE
SKU: 116226 PRC: 151442 EAN: 4015867199190 PN: 8755478

Description

LevelOne AC750 Dual Band PoE Wireless Access Point, Ceiling Mount, Controller Managed, 2.4 GHz, 5 GHz, 433 Mbit/s, 64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP, 10,100,1000 Mbit/s

Specifications

Features

  • 2.4 GHz: Yes
  • 5 GHz: Yes
  • Maximum data transfer rate: 433 Mbit/s
  • Ethernet LAN data rates: 10, 100, 1000 Mbit/s
  • Frequency band: 2.4 - 5.825 GHz
  • Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEE
  • Number of users: 80 user(s)
  • Channels quantity: 36 channels
  • Automatic channel selection: Yes
  • Modulation: 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
  • Wi-Fi Multimedia (WMM)/(WME): Yes
  • Flow control support: Yes
  • Quality of Service (QoS) support: Yes
  • Receiver sensitivity: 2.4GHz: 802.11n (20MHZ): -70 dBm 802.11n (40MHZ): -68 dBm 802.11g: -72 dBm 802.11b: -95 dBm 5GHz: 802.11ac (80MHZ): -62 dBm 802

Security

  • Security algorithms: 64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-AES, WPA2-PSK, WPA2-TKIP
  • Service Set Identifier (SSID) features: SSID broadcast on/off
  • Number of SSID supported: 8

Management features

  • Web-based management: Yes
  • Switch type: Managed
  • Firmware upgradeable: Yes

Ports & interfaces

  • Ethernet LAN (RJ-45) ports: 2
  • WAN connection: Ethernet (RJ-45), Wi-Fi
  • DC-in jack: Yes

Power

  • Power over Ethernet (PoE): Yes
  • Output voltage: 12 V
  • Output current: 1.5 A
  • Power consumption (typical): 15 W

Design

  • Placement: Ceiling, Wall
  • Product colour: White
  • Reset button: Yes
  • LED indicators: Power, WLAN
  • Internal: No

Antenna

  • Antenna direction type: Omni-directional
  • Antenna features: Integrated antenna
  • Antennas quantity: 3
  • Antenna gain level (max): 15 dBi

Certificates

  • Certification: CE/FCC

Weight & dimensions

  • Width: 189 mm
  • Depth: 38.5 mm
  • Height: 189 mm
  • Weight: 326 g

Packaging data

  • Package width: 214 mm
  • Package depth: 62 mm
  • Package height: 317 mm
  • Package weight: 680 g

Packaging content

  • Cables included: LAN (RJ-45)
  • Quick start guide: Yes

Operational conditions

  • Operating relative humidity (H-H): -20 - 50%
  • Operating temperature (T-T): -40 - 70 °C
  • Storage temperature (T-T): 5 - 90 °C
  • Storage relative humidity (H-H): 10 - 90%

Logistics data

  • Harmonized System (HS) code: 85176990
