Description
Server barebone with Intel® 5000P chipset in tower format, ready to work with processors featuring a front-side bus of up to 1333 MHz and supporting ECC memory, a key feature if you are looking for stability in continuous working environments. This Intel MFS5000SI supports up to 31.25 GB of dual-channel DDR2-SDRAM distributed across its 8 DIMM slots, giving you room for configurations with a high data load. The LSI SAS1064E storage controller manages the drives, while network connectivity is handled by an Intel 82563EB controller with two Gigabit Ethernet ports, plus two USB 2.0 ports and a 15-pin front VGA output for the control panel. It includes one PCI Express x8 expansion slot so you can add additional cards as needed.
Specifications
Processor
- Motherboard chipset: Intel® 5000P
- Processor system buses supported: 1333 MHz
- ECC supported by processor: Yes
Memory
- Number of DIMM slots: 8
- Supported memory types: DDR2-SDRAM
- Maximum internal memory: 31.25 GB
- Memory channels: Dual-channel
- ECC: Yes
Storage
- Storage controller: LSI SAS1064E
Graphics
- Maximum graphics card memory: 16 MB
Network
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- LAN controller: Intel® 82563EB
Ports & interfaces
- USB ports quantity: 2
- USB version: 2.0
- Ethernet LAN (RJ-45) ports: 2
- Graphics output: Front Panel 15-pin
Expansion slots
- PCI Express x8 slots: 1
Features
- Embedded options available: No
- Export Control Classification Number (ECCN): 5A992C
- Commodity Classification Automated Tracking System (CCATS): G135162
- ARK ID: 48000
Logistics data
- Harmonized System (HS) code: 8473301180
Design
- Chassis type: Tower
Power
- Thermal Design Power (TDP): 80 W
Packaging data
- Bundled software: Intel Modular Server Control, Intel System Management Software 2.0
Other features
- Graphics card: ES1000
- CPU configuration (max): 2
- On-board graphics card: Yes
- Expected discontinuance date: Q2'10
- Launch date: Q4'08
- Status: Discontinued
- Maximum memory: 31.25 GB
- Product type: Server/Workstation Board
- Product family: Intel compute module
- Product series: Intel MFS5000SI
- Product codename: Sauvie Island
