Name: HUAWEI eKit S220 Series S220-24P4X Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey
Brand: HUAWEI
Availability: OutOfStock

HUAWEI eKit S220 Series S220-24P4X Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey

Not avaliable

HUAWEI eKit S220 Series S220-24P4X Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey. More info

Amount

Brand: HUAWEI

SKU: 106824 PRC: 533530 EAN: 6901443450084 PN: 98012376

Description

24*10/100/1000BASE-T ports(400W PoE+), 4*10GE SFP+ ports, built-in AC power

Specifications

Management features

Switch type: Managed
Switch layer: L2
Quality of Service (QoS) support: Yes
Cloud-managed: Yes
Configuring Location Settings (CLI): Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity: 4
Console port: RJ-45

Network

10G support: Yes
Link aggregation: Yes
Rate limiting: Yes
VLAN support: Yes
Number of VLANs: 4094

Data transmission

Switching capacity: 128 Gbit/s
Forwarding rate: 95 Mpps
MAC address table: 16000 entries
Static route: Yes

Security

DHCP features: DHCP server, DHCP snooping, DHCP client
Access Control List (ACL): Yes
Security algorithms: SNMP, SNMPv2, SNMPv3
Loop protection: Yes
Authentication: MAC-based authentication
Authentication type: IEEE 802.1x

Multicast features

Multicast support: Yes

Design

Rack mounting: Yes
Form factor: 1U
Product colour: Grey
Housing material: Metal
LED indicators: Yes
International Protection (IP) code: IP20

Performance

Noise level: 63 dB

Power

Power source: AC
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (max): 485.91 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 400 W

Operational conditions

Operating temperature (T-T): -5 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 5 - 95%
Operating altitude: 0 - 5000 m
Non-operating altitude: 0 - 5000 m

Weight & dimensions

Width: 442 mm
Depth: 220 mm
Height: 43.6 mm

Packaging data

Package weight: 3.79 kg
