HPE Aruba Networking CX 6200F 48G Class-4 PoE 4SFP+ 740W Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U

Not avaliable

Amount

Brand: HPE

SKU: 110053 PRC: 592113 EAN: 190017634173 PN: jl728b

Description

Specifications

Management features

Switch type: Managed
Switch layer: L3
Quality of Service (QoS) support: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 48
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity: 4
Console port: RJ-45/USB Type-C

Network

Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802
10G support: Yes
Port mirroring: Yes
Flow control support: Yes
Link aggregation: Yes
Auto MDI/MDI-X: Yes
VLAN support: Yes

Optical fiber

Transmission distance (max): 10 km

Data transmission

Latency (1 Gbps): 2.28 µs
Latency (10 Gbps): 1.46 µs
Jumbo frames support: Yes
Packet buffer memory: 8 MB
Switching capacity: 176 Gbit/s
Throughput: 130.9 Mpps
MAC address table: 32768 entries

Security

Access Control List (ACL): Yes
IGMP snooping: Yes
Authentication: MAC-based authentication, Web-based authentication
Authentication type: RADIUS, TACACS+

Multicast features

Multicast support: Yes

Design

Rack mounting: Yes
Stackable: Yes
Form factor: 1U

Performance

Physical stacking (units): 8
Built-in processor: Yes
Processor model: ARM Cortex-A72
Processor frequency: 1800 MHz
Memory type: SDRAM / Flash
Internal memory: 8192 MB
Flash memory: 16384 MB

Power

Power source: AC
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (typical): 76 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 740 W

Operational conditions

Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%
Operating altitude: 0 - 3048 m

Weight & dimensions

Width: 442 mm
Depth: 327 mm
Height: 43.9 mm
Weight: 5.1 kg
