Description
GIGABYTE P650SS ICE Power Supply - PCIe 5.0, 80 PLUS Silver, 120mm Fan, ATX 3.0 compatible, EU Plug, 650 W, 155-240 V, 50/60 Hz, 6.3 A, Active, 100 W
Specifications
Power
- Total power: 650 W
- AC input voltage: 155-240 V
- AC input frequency: 50/60 Hz
- Input current: 6.3 A
- Power factor: 0.9
- Power Factor Correction (PFC) type: Active
- Combined power (+3.3V): 100 W
- Combined power (+12V): 649.2 W
- Combined power (+5V): 100 W
- Combined power (-12V): 3.6 W
- Combined power (+5Vsb): 15 W
- Max output current (+3.3V): 20 A
- Max output current (+12V): 54.1 A
- Max output current (+5V): 20 A
- Max output current (-12V): 0.3 A
- Max output current (+5Vsb): 3 A
- Power Good signal delay range: 100 - 150 ms
- Power protection features: Over power, Overcharge, Short circuit, Under voltage
Ports & interfaces
- Motherboard power connector: 20+4 pin ATX
- Motherboard power cable length: 60 cm
- Number of SATA power connectors: 5
- SATA power cable length: 120, 500 mm
- Peripheral (Molex) power connectors (4-pin): 2
- Peripheral (Molex) power cable length: 120, 500 mm
- PCI Express power connectors (6+2 pin): 2
- PCI Express power cable length: 65 cm
- CPU P4 connector (4-pin): 1
- CPU power connector (4+4 pin): Yes
- CPU power cable length: 60 cm
- ATX power connector (20+4 pin): Yes
- Floppy disk drive connector: Yes
- Cabling type: Non-Modular
Performance
- 80 PLUS certification: 80 PLUS Silver
- Purpose: PC
- Power supply unit (PSU) form factor: ATX
- ATX version: 3.0
- Bearing technology: FDB
- Mean time between failures (MTBF): 100000 h
Design
- Product colour: White
- Cooling type: Active
- Fan diameter: 12 cm
- Number of fans: 1 fan(s)
- Fan location: Top
- On/off switch: Yes
Weight & dimensions
- Width: 140 mm
- Depth: 150 mm
- Height: 86 mm
- Weight: 2.23 kg
Packaging data
- Package width: 254 mm
- Package depth: 206 mm
- Package height: 117 mm
- Package weight: 2.6 kg
- Package type: Box
Logistics data
- Warranty period: 3 year(s)
