Description
Managed, L2+, 20 Gbps switching capacity, 8x RJ-45, 2x SFP, PoE, QoS
Specifications
Management features
- Switch type: Managed
- Switch layer: L2+
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 8
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP module slots quantity: 2
Network
- Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
- 10G support: No
- Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Port mirroring: Yes
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Spanning tree protocol: Yes
- Ethernet LAN data rates: 10,100,1000 Mbit/s
- IPv4 routes: 59
- IPv6 routes: 5
- VLAN support: Yes
- Virtual LAN features: Port-based VLAN, Tagged VLAN, Voice VLAN
Data transmission
- Switching capacity: 20 Gbit/s
- MAC address table: 8000 entries
- Static route: Yes
- Number of static routes: 192
- Jumbo frames support: Yes
- Jumbo frames: 9000
Security
- DHCP features: DHCP relay, DHCP snooping
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Security algorithms: SNMP, SNMPv2, SNMPv3
- SSH/SSL support: Yes
- Authentication type: RADIUS
Multicast features
- Multicast support: Yes
- Multicast MAC address table: 256 entries
Protocols
- GARP VLAN Registration Protocol (GVRP): Yes
- IPv4 & IPv6 features: IPv4/IPv6 access-control list (ACL), IPv6 ping
Design
- Rack mounting: Yes
- Product colour: Black
- LED indicators: Fault, LAN, PoE, Power
Performance
- Memory type: SDRAM
- Internal memory: 256 MB
- Flash memory: 32 MB
- Firmware upgradeable: Yes
Power
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 8
- Total Power over Ethernet (PoE) budget: 55 W
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
- Width: 105 mm
- Depth: 240 mm
- Height: 27 mm
- Weight: 620 g
Packaging content
- Manual: Yes
Packaging data
- Package width: 168 mm
- Package depth: 271 mm
- Package height: 85 mm
- Package weight: 1.5 kg
Certificates
- Certification: CE, FCC, IC
