Description

Specifications

Performance


  • Type: IP security camera
  • Placement supported: Indoor & outdoor
  • Connectivity technology: Wired
  • Thermal module: Yes
  • Thermal sensitivity (NETD): 40 mK
  • Certification: CE (EN 60950: 2000) FCC (FCC Part 15 SubpartB )

Design


  • Form factor: Bullet
  • Mounting type: Wall
  • Product colour: Black, White
  • Housing material: Metal
  • International Protection (IP) code: IP67

Camera


  • Lens viewing angle, horizontal: 11.1°
  • Lens viewing angle, vertical: 8.3°
  • Camera pixel size: 17 µm

Image sensor


  • Sensor type (thermal module): Vanadium Oxide Uncooled Focal Plane Arrays
  • Effective sensor resolution (thermal module): 400 x 300 pixels

Lens system


  • Digital zoom: 4x
  • Number of lenses: 1
  • Focal length range: 7.5 - 35 mm
  • Fixed focal length: 1 mm

Video


  • Video formats supported: H.264, H.265
  • Video compression formats: H.264, H.265
  • Supported graphics resolutions: 400 x 300, 640 x 512, 1280 x 1024 (SXGA)
  • Supported video modes: 720p
  • Frame rate: 30 fps
  • Flip & mirror: Yes
  • Bit rate control: Constant Bit Rate (CBR), Variable Bit Rate (VBR)
  • Bit rate: 640 ~ 8192
  • Region of Interest (ROI) encoding: Yes

Audio


  • Audio input channels: 1.0 channels
  • Audio output channels: 1.0 channels
  • Audio formats supported: AAC, G.711 A-law, G.711 μ-law, PCM

Network


  • Ethernet LAN: Yes
  • Supported network protocols: IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter,
  • Wi-Fi: No
  • Bluetooth: No
  • Number of users: 20 user(s)
  • Streaming method: Multicast, Unicast

Storage


  • Built-in HDD: No
  • Compatible memory cards: MicroSD (TransFlash)
  • Maximum memory card size: 256 GB

Ports & interfaces


  • Ethernet LAN (RJ-45) ports: 1
  • RS-485 ports: 1

Security


  • Alarm input channels: 2
  • Alarm output channels: 2
  • Fire detection: Yes
  • Video motion detection: Yes
  • Privacy protection: Yes
  • Intelligent Video Surveillance (IVS) system features: Intrusion, Tripwire
  • Mirror: Yes
  • Human and vehicle targets classification: Yes

Power


  • Power source type: DC, PoE
  • Power consumption (max): 13 W
  • DC output voltage: 12

Operational conditions


  • Operating temperature (T-T): -40 - 70 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 0 - 95%
  • Storage relative humidity (H-H): 0 - 95%

Weight & dimensions


  • Width: 103 mm
  • Depth: 291 mm
  • Height: 97 mm
  • Weight: 1.5 kg

Packaging data


  • Package weight: 1.9 kg

Packaging content


  • Number of cameras: 1
