Dahua Technology Pro TPC-BF5441 Bullet IP security camera Indoor & outdoor 2688 x 1520 pixels Ceiling/wall

Name: Dahua Technology Pro TPC-BF5441 Bullet IP security camera Indoor & outdoor 2688 x 1520 pixels Ceiling/wall
Brand: DAHUA TECHNOLOGY
SKU: 680323
Price: 1555.26 EUR
Availability: InStock

More info

Brand: DAHUA TECHNOLOGY

1,555.26 €

1,285.34 € without VAT incl. 21 % VAT

Stock available: 2 units.

Get it on the October 16 / October 19

SKU: 134225 PRC: 680323 EAN: 6923169715025

Description

The Dahua Technology TPC-BF5441 is an indoor and outdoor IP security camera with a 2688 x 1520 pixel sensor and a 400 x 300 pixel thermal sensor. Its form factor is bullet type and it is mounted on the ceiling or wall. It features IP67 protection, a shutter speed from 1 to 1/30000 seconds adjustable in automatic or manual mode and a NETD thermal sensitivity of 35 mK. It records in resolutions ranging from 352 x 288 to 2688 x 1520, including 1280 x 720 and 1920 x 1080, and supports MicroSD cards up to 512 GB. Connectivity is wired via Fast Ethernet, with an RJ-45 port, an RS-485 port and a BNC output, as well as two alarm input channels.

Specifications

Performance

Infrared (IR) cut-off filter: Yes
Alarm input/output: Yes
Thermal sensitivity (NETD): 35 mK
Type: IP security camera
Placement supported: Indoor & outdoor
Connectivity technology: Wired
Thermal module: Yes
Wide Dynamic Range (WDR): Yes
Day/night mode: Yes

Design

Form factor: Bullet
Mounting type: Ceiling/wall
Product colour: Black, White
International Protection (IP) code: IP67
Fog proof: Yes

Camera

Minimum illumination: 0.001 lx
Vertical field of view (thermal module): 39.5°
Horizontal field of view (thermal module): 53.5°
Lens viewing angle, horizontal: 84°
Lens viewing angle, vertical: 47.3°
White balance: Auto, Indoor, Manual, Natural, Outdoor, Sodium lamp, Street lamp
Camera shutter type: Electronic
Camera shutter speed: 1 - 1/30000 s
Adjustment shutter speed: Auto/Manual

Image sensor

Number of sensors: 1
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Sensor type (thermal module): Vanadium Oxide Uncooled Focal Plane Arrays
Effective sensor resolution (thermal module): 400 x 300 pixels
Sensor type: CMOS
Number of effective pixels (H x V): 2688 x 1520 pixels

Lens system

Zoom capability: Yes
Digital zoom: 19x
Number of lenses: 1
Fixed focus: Yes
Maximum aperture number: 1.6
Fixed focal length: 4 mm
Closest focusing distance: 1.2 m
Infrared spectral band: 8 - 14 µm

Night vision

Night vision: Yes

Video

Maximum resolution: 2688 x 1520 pixels
Total megapixels: 4 MP
Video compression formats: H.264B, H.264H, H.264M, H.265
Supported graphics resolutions: 352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 2688 x 1520
Supported video modes: 576p, 720p, 1080p, 1440p, 1520p
Noise reduction: Yes
Noise reduction technology: 2D noise reduction, 3D noise reduction
Gain control type: Auto/Manual
Flip & mirror: Yes
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Region of Interest (ROI) encoding: Yes

Audio

Signal-to-Noise Ratio (SNR): 55 dB
Voice codecs: G.711Mu, G.711a

Network

Ethernet LAN: Yes
Ethernet interface type: Fast Ethernet
Networking standards: IEEE 802.1x, IEEE 802.3af
Supported network protocols: IPv4/IPv6; HTTP; HTTPS; 802.1x; QoS; FTP; SMTP; UPnP; SNMP; DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE
Wi-Fi: No
Bluetooth: No
Number of users: 20 user(s)
