Description
600 W, ATX 2.51, 200-240 VAC, 6 A, 120mm fan
Specifications
Power
- Total power: 600 W
- AC input voltage: 200 - 240 V
- AC input frequency: 50 Hz
- Input current: 6 A
- Power factor: 0.95
- Power Factor Correction (PFC) type: Active
- Combined power (+3.3V): 120 W
- Combined power (+12V): 576 W
- Combined power (+5V): 120 W
- Combined power (-12V): 3.6 W
- Combined power (+5Vsb): 15 W
- Max output current (+3.3V): 24 A
- Max output current (+12V1): 28 A
- Max output current (+12V2): 22 A
- Max output current (+5V): 15 A
- Max output current (-12V): 0.3 A
- Max output current (+5Vsb): 3 A
- Hold time: 17 ms
- Efficiency: 89%
- Power protection features: Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage
Ports & interfaces
- Motherboard power connector: 20+4 pin ATX
- Motherboard power cable length: 55 cm
- Number of SATA power connectors: 6
- Number of PATA power connectors: 2
- SATA power cable length: 550,670 mm
- PCI Express power connectors (6+2 pin): 4
- PCI Express power cable length: 50 cm
- CPU power connector (4+4 pin): Yes
- CPU power cable length: 60 cm
- Floppy drive power connector: 1
- Cabling type: Semi-Modular
Performance
- 80 PLUS certification: 80 PLUS Bronze
- Purpose: PC
- Power supply unit (PSU) form factor: ATX
- ATX version: 2.51
- EPS version: 2.92
- Noise level (silent mode,: 9.2 dB
- Noise level (quiet mode, 50%): 12.8 dB
- Noise level (full-load mode, 100%): 31.2 dB
- Bearing technology: Sleeve
- RoHS compliance: Yes
- Energy Star certified: Yes
- Certification: CE, CB, TÜV, RCM, CU
- Compatible products: Intel C6/C7
Design
- Product colour: Black
- Cooling type: Active
- Fan diameter: 12 cm
- Number of fans: 1 fan(s)
Weight & dimensions
- Width: 150 mm
- Depth: 140 mm
- Height: 86 mm
- Weight: 1.66 kg
Packaging data
- Screws included: Yes
- Manual: Yes
- Package width: 97 mm
- Package depth: 268 mm
- Package height: 195 mm
- Package weight: 2.42 kg
- Package type: Box
Logistics data
- Master (outer) case width: 31.1 cm
- Master (outer) case length: 21.5 cm
- Master (outer) case height: 55.6 cm
- Master (outer) case weight: 15.2 kg
- Quantity per master (outer) case: 6 pc(s)
