Description
The ATEN CE920-ATA-G is a KVM extender transmitter and receiver in black, with a metal housing and rack-mount design, intended to extend control of a computer from a remote room. It connects keyboard, mouse and video via cable through RJ-45 ports, supporting Cat5e, Cat6 and Cat6a cables to achieve a maximum transmission distance of 150 metres. It supports a maximum digital resolution of 4096 x 2160 pixels thanks to its DisplayPort and USB ports, and includes four USB 2.0 ports and audio connectors for PC input and output. The integrated LED indicators facilitate monitoring of the connection status.
Specifications
Features
- Type: Transmitter & receiver
- Connectivity technology: Wired
- Maximum transfer distance: 150 m
- Cable types supported: Cat5e, Cat6, Cat6a
- Rack mounting: Yes
- Maximum digital resolution: 4096 x 2160 pixels
- Product colour: Black
- Material: Metal
- LED indicators: Yes
Transmitter
- Transmitter video port type: DisplayPort
- Transmitter local keyboard/mouse port type: USB
- RJ-45 ports quantity (transmitter): 1
Receiver
- Receiver local video port type: DisplayPort
- Receiver local keyboard/mouse port type: USB
- RJ-45 ports quantity (receiver): 1
Ports & interfaces
- USB 2.0 ports quantity: 4
- USB data transfer rates: 480 Mbit/s
- PC Audio in: Yes
- PC Audio out: Yes
Power
- AC adapter output voltage: 5 V
- Power consumption (transmitter) (max): 3.99 W
- Power consumption (receiver) (max): 6.74 W
Weight & dimensions
- Transmitter width: 18.2 cm
- Transmitter depth: 12.2 cm
- Transmitter height: 2.87 cm
- Transmitter weight: 630 g
- Receiver width: 18.2 cm
- Receiver depth: 12.2 cm
- Receiver height: 2.87 cm
- Receiver weight: 650 g
Packaging data
- Package width: 98 mm
- Package depth: 325 mm
- Package height: 210 mm
- Package weight: 2.18 kg
Packaging content
- AC adapter included: Yes
- Cables included: DisplayPort
- Manual: Yes
- Mounting bracket(s) included: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 80%
