Description
10-metre active optical cable with HDMI type D (Micro) connectors transmitting True 4K at 60 Hz with a bandwidth of 600 MHz and a transfer speed of 18 Gbit/s. Its minimum bending radius of 2 cm facilitates installation in tight spaces, while the strain-relief connector and gold-plated contacts ensure a stable connection. Compatible with 3D, HDR, 4:4:4 colour sampling, and Dolby TrueHD or DTS-HD Master Audio, as well as being Plug and Play with EDID support. The Plenum (OFNP) cable jacket and copper conductor offer a robust construction for professional use.
Specifications
Features
- Cable length: 10 m
- Connector 1: HDMI Type D (Micro)
- Connector 2: HDMI Type D (Micro)
- Connector 1 gender: Male
- Connector 2 gender: Male
- Connector 1 form factor: Straight
- Connector 2 form factor: Straight
- Product colour: Black
- 3D: Yes
- Supported graphics resolutions: 3840 x 2160, 4096 x 2160
- Dolby technologies: DTS-HD Master Audio, Dolby TrueHD
- Pull-resistant connector(s): Yes
- Pull-off force: 10 kg
- Audio Return Channel (ARC): Yes
- HDMI Ethernet channel: Yes
- HDCP: Yes
- HDCP version: 2.2
- Data transfer rate: 18 Gbit/s
- High Dynamic Range (HDR) supported: Yes
- Bandwidth: 600 MHz
- Maximum refresh rate: 60 Hz
- Connector contacts plating: Gold
- Cable material: Copper
- Cable jacket material: Plenum (OFNP)
- Bending radius (min): 2 cm
- Cable shielding: Aluminum mylar foil
- Plug and Play: Yes
- Colour sampling: 4:4:4
- Extended display identification data (EDID): Yes
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 70 °C
- Operating relative humidity (H-H): 0 - 85%
Certificates
- Certification: CE, FCC, RoHS2, UL CMP-OF
Weight & dimensions
- Cable diameter: 4.5 mm
- Weight: 700 g
- Package volume: 3964.359 cm³
Packaging content
- Interface adapters included: Micro HDMI female - HDMI male
- Manual: Yes
- Screwdriver included: Yes
Packaging data
- Package width: 225 mm
- Package depth: 235 mm
- Package height: 74 mm
- Package weight: 700 g
- Quantity per pack: 1 pc(s)
Logistics data
- Country of origin: China
- Master (outer) case net weight: 7 kg
- Master (outer) case width: 385 mm
- Master (outer) case length: 470 mm
- Master (outer) case height: 265 mm
- Master (outer) case gross weight: 8 kg
- Master (outer) case volume: 47855.471 cm³
