Ubiquiti UniFi USW-48-POE network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Stainless steel
More info
Brand: UBIQUITI NETWORKS
699.72 €
578.28 €
without VAT
incl. 21 % VAT
Stock available: 1 ud.
Get it
tomorrow
/
October 29
SKU:
85927
PRC:
298848
EAN:
810010072146
PN:
usw-48-poe
Description
Managed L2 switch from the UniFi series, the USW-48-POE from Ubiquiti Networks offers 48 Gigabit Ethernet ports with PoE power according to the IEEE 802.3af and 802.3at standards, plus 4 SFP slots for fibre uplinks. Its switching capacity reaches 104 Gbit/s, with a forwarding rate of 77.38 Mpps, and it supports jumbo frames, VLAN, flow control, port mirroring, link aggregation and spanning tree protocol. Designed in a 1U format with a stainless steel chassis, this model integrates into standard racks and manages the network via the centralised UniFi interface, with automatic device detection and MDI/MDI-X auto-negotiation on all its ports.
Specifications
Management features
- Switch type: Managed
- Switch layer: L2
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP module slots quantity: 4
Network
- Networking standards: IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
- 10G support: No
- Port mirroring: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Auto MDI/MDI-X: Yes
- Spanning tree protocol: Yes
- Auto-sensing: Yes
- VLAN support: Yes
Data transmission
- Switching capacity: 104 Gbit/s
- Throughput: 52 Gbit/s
- Forwarding rate: 77.38 Mpps
- Jumbo frames support: Yes
Security
- Authentication type: RADIUS
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Stainless steel
- LED indicators: Activity, Link, Speed
Performance
- Fanless: Yes
Power
- Power source: AC/DC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption (max): 45 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet plus (PoE+) ports quantity: 32
- Power over Ethernet (PoE) power per port: 32 W
- Total Power over Ethernet (PoE) budget: 195 W
Operational conditions
- Operating temperature (T-T): -5 - 40 °C
- Operating relative humidity (H-H): 10 - 90%
Weight & dimensions
- Width: 442.4 mm
- Depth: 285 mm
- Height: 43.7 mm
- Weight: 4.52 kg
Packaging content
- Manual: Yes
Certificates
- Certification: CE, FCC, IC
