Name: TP-Link VIGI C485 Turret IP security camera Outdoor 3840 x 2160 pixels Ceiling
Brand: TP-LINK
Availability: OutOfStock

TP-Link VIGI C485 Turret IP security camera Outdoor 3840 x 2160 pixels Ceiling

Not avaliable

Amount

Brand: TP-LINK

SKU: 108679 PRC: 550391 EAN: 4895252502466 PN: VIGIC485_2.8MM

Description

TP-Link VIGI C485, IP security camera, Outdoor, Wired, 120 dB, Ceiling, White

Specifications

Performance

Type: IP security camera
Placement supported: Outdoor
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Day/night mode: Yes
Infrared (IR) cut-off filter: Yes
Built-in light: Yes
Dynamic range: 120 dB

Design

Form factor: Turret
Mounting type: Ceiling
Product colour: White
Housing material: Metal
International Protection (IP) code: IP67

Camera

Minimum illumination: 0.005 lx
Angle of rotation: 360°
Lens viewing angle, horizontal: 111.4°
Lens viewing angle, vertical: 58.8°
Lens viewing angle, diagonal: 134°
Tilt angle range: 0 - 85°
Pan range: 0 - 360°
Camera shutter speed: 1/3 to 1/10000
Number of Privacy masking areas: 4

Image sensor

Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Progressive scan: Yes
Sensor type: CMOS

Lens system

Number of lenses: 1
Detect distance: 85 m
Observe distance: 35 m
Recognize distance: 17 m
Maximum aperture number: 1.6
Identify distance: 8 m
Fixed focal length: 2.8 mm

Night vision

Night vision: Yes
Night vision distance: 30 m
LED type: IR/White
Number of illumination LEDs: 4
Infra-red wavelength: 850 nm

Video

Maximum resolution: 3840 x 2160 pixels
Total megapixels: 8 MP
Video compression formats: H.264, H.264+, H.265, H.265+
Supported graphics resolutions: 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 3840 x 2160
Frame rate: 25 fps
Video streaming: Yes
Noise reduction: Yes
Noise reduction technology: 3D noise reduction
Image quality adjustment: Brightness, Contrast, Mirror, Saturation, Sharpness
Privacy masking: Yes
Bit rate control: Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Region of Interest (ROI) encoding: Yes
Smart IR: Yes

Audio

Built-in speaker(s): Yes
Audio system: 2-way
Audio formats supported: G.711
Sample rate: 8 kHz
Signal-to-Noise Ratio (SNR): 52 dB
Built-in microphone: Yes

Network

Ethernet LAN: Yes
Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Wi-Fi: No
Bluetooth: No
Live view: Yes

Storage

Built-in HDD: No
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash)
Maximum memory card size: 512 GB

Ports & interfaces

Ethernet LAN (RJ-45) ports: 1
DC-in jack: Yes

Security

Password protection: Yes
Video motion detection: Yes
IP address filtering: Yes
HTTPS encryption: Yes
Human and vehicle targets classification: Yes

Management features

Reset button: Yes

Power

Power source type: DC, PoE
Power consumption (max): 11.5 W
Power consumption (Power over Ethernet (PoE)): 12.5 W
DC output voltage: 12

Operational conditions

Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -40 - 60 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%

Weight & dimensions

Width: 111 mm
Depth: 111 mm
Height: 83.7 mm
Weight: 480 g

Packaging content

Number of cameras: 1
Mounting kit: Yes
Waterproof connector: Yes
