Performance


  • Type: IP security camera
  • Placement supported: Indoor
  • Connectivity technology: Wired
  • Wide Dynamic Range (WDR): Yes
  • Day/night mode: Yes
  • Infrared (IR) cut-off filter: Yes

Design


  • Form factor: Turret
  • Mounting type: Ceiling
  • Product colour: White
  • Housing material: Plastic

Camera


  • Minimum illumination: 0.1 lx
  • Lens viewing angle, horizontal: 88.8°
  • Lens viewing angle, vertical: 48.9°
  • Lens viewing angle, diagonal: 106.5°

Image sensor


  • Optical sensor size: 25.4 / 3 mm (1 / 3")
  • Progressive scan: Yes
  • Sensor type: CMOS

Lens system


  • Number of lenses: 1
  • Maximum aperture number: 2.2
  • Normal focusing range: 2.8 m

Night vision


  • Night vision: Yes
  • Night vision distance: 30 m
  • LED type: IR
  • Infra-red wavelength: 850 nm

Video


  • Maximum resolution: 2560 x 1440 pixels
  • Total megapixels: 4 MP
  • Video compression formats: H.264, H.264+, H.265, H.265+
  • Supported graphics resolutions: 320 x 240, 352 x 288, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440
  • Supported video modes: 240p, 480p, 720p, 1080p, 1280p, 1440p
  • Frame rate: 30 fps
  • Video streaming: Yes
  • Noise reduction: Yes
  • Noise reduction technology: 3D noise reduction
  • Image quality adjustment: Brightness, Contrast, DNR, Mirror, Saturation
  • Bit rate: 64 Kbps - 4 Mbps
  • Back Light Compensation (BLC): Yes
  • Highlight Compensation (HLC): Yes
  • Digital Wide Dynamic Range (DWDR): Yes
  • Region of Interest (ROI) encoding: Yes
  • Smart IR: Yes
  • 3D positioning: Yes

Network


  • Ethernet LAN: Yes
  • Networking standards: IEEE 802.3af, IEEE 802.3at
  • Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
  • Wi-Fi: No
  • Bluetooth: No
  • Number of simultaneous live view channels: 3 channels

Ports & interfaces


  • Ethernet LAN (RJ-45) ports: 1

Security


  • Password protection: Yes
  • Video motion detection: Yes
  • Active tampering alarm: Yes
  • IP address filtering: Yes
  • HTTPS encryption: Yes
  • Mirror: Yes
  • Password reset via email: Yes
  • Human and vehicle targets classification: Yes
  • Digest authentication: Yes

Management features


  • Behavior analysis: Intrusion detection, Line crossing detection, Object removal detection, Region entrance detection, Region exiting detection

Power


  • Power source type: DC, PoE
  • Power consumption (max): 5 W
  • DC output voltage: 12

Operational conditions


  • Operating temperature (T-T): -30 - 60 °C

Weight & dimensions


  • Width: 123 mm
  • Depth: 83 mm
  • Height: 123 mm

Packaging data


  • Package width: 163 mm
  • Package depth: 163 mm
  • Package height: 116 mm
  • Package weight: 350 g

Sustainability


  • Sustainability compliance: Yes
  • Compliance certificates: BSMI, CE

Packaging content


  • Number of cameras: 1
  • Mounting kit: Yes
  • Manual: Yes
