Description
The TP-Link VIGI NVR2008H-8MP network video recorder, in black, manages up to 8 video input channels and reaches a maximum resolution of 3840 x 2160 pixels. It supports H.264, H.264+, H.265 and H.265+ video formats, and works with resolutions ranging from 1280 x 720 to 3840 x 2160, with a maximum frame rate of 60 fps. Its input bandwidth is 80 Mbit/s and output bandwidth is 60 Mbit/s. It incorporates video motion detection and video loss detection, and offers compatibility with G.711, G.711u and G.726 audio formats. For storage it has two bays with SATA interface and a maximum capacity of 32 TB. As for connectivity, it features 9 RJ-45 10/100 Mbit/s Ethernet LAN ports, one VGA output and one RCA audio output. Its dimensions are 330 x 45 x 285 mm (width x height x depth) and its weight is 2.1 kg.
Specifications
Performance
- Video input channels: 8 channels
- Maximum resolution: 3840 x 2160 pixels
- Supported resolutions: 3840x2160, 1920x1080, 1680x1050, 1440x900, 1280x1024, 1280x720
- Video motion detection: Yes
- Video loss detection: Yes
- Audio formats supported: G.711, G.711u, G.726
- Video formats supported: H.264, H.264+, H.265, H.265+
- Maximum frame rate: 60 fps
- Input bandwidth: 80 Mbit/s
- Output bandwidth: 60 Mbit/s
Wireless LAN features
- Wi-Fi: No
Hard drive
- Number of HDDs supported: 2
- Maximum storage capacity: 32 TB
- HDD interface: SATA
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 9
- Power over Ethernet (PoE): Yes
- Ethernet LAN data rates: 10, 100 Mbit/s
- HDMI ports quantity: 1
- VGA (D-Sub) output ports: 1
- USB 2.0 ports quantity: 2
- Audio RCA inputs: 1
- Audio RCA outputs: 1
- eSATA: Yes
- DC-in jack: Yes
Features
- LED indicators: Yes
- Product colour: Black
Power
- Power consumption (typical): 35 W
- Output current: 2.43 A
- Output voltage: 53.5 V
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 93 W
Operational conditions
- Operating temperature (T-T): -10 - 55 °C
- Operating relative humidity (H-H): 10 - 90%
- Storage temperature (T-T): -40 - 70 °C
- Storage relative humidity (H-H): 10 - 90%
Weight & dimensions
- Width: 330 mm
- Depth: 285 mm
- Height: 45 mm
- Weight: 2.1 kg
- Package weight: 4.1 kg
