Name: NETGEAR M4350-32F8V Managed L3 1U Black
Brand: NETGEAR
Price: 5384.57 USD
Availability: InStock

NETGEAR M4350-32F8V Managed L3 1U Black

$5,384.57

$5,384.57 without VAT

NETGEAR M4350-32F8V Managed L3 1U Black. More info

Amount

Brand: NETGEAR

SKU: 116683 PRC: 524310 EAN: 606449165166 PN: XSM4340FV-100NES

Description

32 x 10G SFP+, 8 x 25G SFP28, 440 x 400 x 43.2 mm, 6.95 kg

Specifications

Management features

Switch type: Managed
Switch layer: L3
Quality of Service (QoS) support: Yes
Web-based management: Yes
ARP inspection: Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports type: No
SFP+ module slots quantity: 32
SFP28 ports quantity: 8
Power connector: AC-in jack

Network

Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802
10G support: Yes
Full duplex: Yes
Policy-based routing: Yes
Flow control support: Yes
Link aggregation: Yes
Broadcast storm control: Yes
Rate limiting: Yes
Spanning tree protocol: Yes
6to4 tunnel: Yes
IPv4 routes: 512
IPv6 routes: 256
VLAN support: Yes
Virtual LAN features: MAC address-based VLAN, Private VLAN, Voice VLAN
Number of VLANs: 4093

Data transmission

Switching capacity: 1040 Gbit/s
Throughput: 773.76 Mpps
MAC address table: 16000 entries
Store-and-forward: Yes
Latency (10 Gbps): 1.27 µs
Jumbo frames support: Yes
Jumbo frames: 12000
Packet buffer memory: 64 MB

Security

DHCP features: DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping
Access Control List (ACL): Yes
Access Control List (ACL) egress: 1023
Access Control List (ACL) ingress: 511
IGMP snooping: Yes
IGMP proxy: Yes
MAC address filtering: Yes
Static port security: Yes
Loop protection: Yes
BPDU filtering/protection: Yes
Authentication: Guest VLAN, MAC-based authentication
Root protection: Yes
Password protection: Yes
DoS attack prevention: Yes
Authentication type: RADIUS, TACACS+
Queue scheduling algorithms: Strict Priority Queue (SPQ), Weighted random early detection (WRED)

Multicast features

Multicast support: Yes
Multicast Listener Discovery (MLD) snooping: Yes

Protocols

Management protocols: SNMP V1, V2, V3
GARP VLAN Registration Protocol (GVRP): Yes
Routing protocols: OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2

Design

Rack mounting: Yes
Stackable: Yes
Form factor: 1U
Product colour: Black
LED indicators: Yes
Airflow direction: Front-to-back airflow

Performance

Built-in processor: Yes
Processor model: ARM Cortex-A57
Processor frequency: 1800 MHz
Memory type: DDR4-SDRAM
Internal memory: 4096 MB
Flash memory: 512 MB
sFlow: Yes

Power

Power source: AC
Power supply included: Yes
Power consumption (typical): 156.4 W

Power over Ethernet (PoE)

Power over Ethernet (PoE): No

Other features

Power supply: 420 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 3000 m

Weight & dimensions

Width: 440 mm
Depth: 400 mm
Height: 43.2 mm
Weight: 6.95 kg

Packaging content

Cables included: AC, USB Type-C
Quick start guide: Yes
Rack mount kit: Yes

Packaging data

Included power plug types: EU, NA, UK

Sustainability

Sustainability compliance: Yes

Certificates

Compliance certificates: BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
