Description
The Lindy 38365 is a black AV signal transmitter that extends video and audio content over Cat6 cable up to 100 metres, with support for maximum resolutions of 3840 x 2160 pixels at 60 Hz and a bandwidth of 18 Gbit/s. This unit includes an HDMI 2.0b output and HDCP compatibility in versions 1.4 and 2.2, as well as 2.0-channel audio output channels. It features RS-232 ports, an SFP+ connector for fibre optic, USB type A and type B connectors (version 2.0), a 3.5 mm input, and a DC input socket for power. Designed for professional installations, this transmitter facilitates the distribution of high-quality AV signals in environments requiring long distances without perceptible loss.
Specifications
Features
- Type: AV transmitter
- Maximum resolution: 3840 x 2160 pixels
- Cable types supported: Cat6
- Maximum transfer distance: 100 m
- Maximum refresh rate: 60 Hz
- Audio output channels: 2.0 channels
- Bandwidth: 18 Gbit/s
- HDCP: Yes
- HDCP version: 1.4/2.2
- Product colour: Black
Ports & interfaces
- Connectivity technology: Wired
- Ethernet LAN: Yes
- RJ-45 input ports: 2
- HDMI in: 1
- Number of HDMI outputs: 1
- HDMI version: 2.0b
- Fiber optic connector: SFP+
- Fiber ports quantity: 1
- USB ports quantity: 3
- USB version: 2.0
- USB connector type: USB Type-A, USB Type-B
- Serial ports quantity: 1
- Serial interface type: RS-232
- 3.5 mm (1/8-inch) in: Yes
- 3.5 mm (1/8-inch) out: Yes
- Remote (IR) input: 1
- Remote (IR) output: 1
- DC-in jack: Yes
Power
- Power source type: DC
- Operating voltage: 12 V
- Output current: 1 A
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 20 - 90%
- Storage relative humidity (H-H): 20 - 90%
Weight & dimensions
- Width: 204 mm
- Depth: 134 mm
- Height: 21.5 mm
- Weight: 980 g
Packaging data
- Quantity per pack: 1 pc(s)
- Package width: 245 mm
- Package depth: 185 mm
- Package height: 75 mm
- Package weight: 1.3 kg
- Package type: Box
Packaging content
- AC adapter included: Yes
- Cables included: IR
- Included power plug types: AU, EU, UK, US
- Quick start guide: Yes
- Mounting kit: Yes
Technical details
- Sustainability compliance: Yes
- Compliance certificates: Federal Communications Commission (FCC), UKCA, CE, REACH, RoHS
