Return

Description

Specifications

Features


  • Connector 1 form factor: Straight
  • Connector 2 form factor: Straight
  • Connector contacts plating: Gold
  • Cable length: 2 m
  • Connector 1: DisplayPort
  • Connector 2: HDMI Type A (Standard)
  • Connector 1 gender: Male
  • Connector 2 gender: Male
  • HDMI version: 1.4
  • DisplayPort version: 1.2
  • Maximum resolution: 3840 x 2160 pixels
  • Supported graphics resolutions: 3840 x 2160
  • Supported video modes: 1080p
  • Data transfer rate: 10.2 Gbit/s
  • Maximum refresh rate: 30 Hz
  • Bend radius (min): 7.3 cm
  • Product colour: Black
  • Conductor material: Tinned copper
  • Nominal attenuation: 100MHz~450MHz -2.44--5.099dB 450MHz~8100MHz -5.094~32.906dB
  • Jacket material: Polyvinyl chloride (PVC)
  • Cable type: Round cable
  • Connector housing material: Polyvinyl chloride (PVC) / Acrylonitrile butadiene styrene (ABS)
  • Connector material: Gold
  • Contact material: Copper
  • AWG wire size: 28
  • Colour depth: 8 bit
  • Colour sampling: 4:4:4
  • Cable shielding: Aluminium braid

Operational conditions


  • Operating temperature (T-T): 0 - 45 °C
  • Storage temperature (T-T): -10 - 80 °C

Certificates


  • Certification: CE, UKCA, FCC, RoHS, REACH, UL, California

Weight & dimensions


  • Cable diameter: 7.3 mm
  • Connector 1 dimensions (WxDxH): 36.4 x 20.5 x 9.4 mm
  • Connector 2 dimensions (WxDxH): 37.5 x 20.5 x 10.5 mm

Packaging data


  • Package type: Polybag

Packaging content


  • Quantity per pack: 1 pc(s)

Logistics data


  • Harmonized System (HS) code: 84733080
