Description
The LevelOne HVE-9010 is an AV signal transmitter and receiver that allows audio and video to be sent over cable between two points. It offers a maximum resolution of 3840 x 2160 pixels with a refresh rate of up to 30 Hz, plus a bandwidth of 3 Gbit/s. The maximum transfer distance reaches 50 m, so you can separate the source and destination equipment without losing the signal. Its connectivity includes one HDMI input, one HDMI output, one RJ-45 input port and one RJ-45 output port, along with two inputs and two outputs for infrared pass-through, which allows the remote device to be controlled. It also supports HDCP and is plug and play. The DC input plug operates at an operating voltage of 5 V. This black model weighs 490 g and its measurements are 85 x 27 x 85 mm (width x height x depth), a compact format to place next to the screen or the receiver.
Specifications
Features
- Type: AV transmitter & receiver
- Maximum resolution: 3840 x 2160 pixels
- Maximum transfer distance: 50 m
- Maximum refresh rate: 30 Hz
- IR pass-through: Yes
- Bandwidth: 3 Gbit/s
- HDCP: Yes
- Plug and Play: Yes
- Product colour: Black
Ports & interfaces
- Connectivity technology: Wired
- RJ-45 input ports: 1
- RJ-45 output ports: 1
- HDMI in: 1
- Number of HDMI outputs: 1
- Remote (IR) input: 2
- Remote (IR) output: 2
- DC-in jack: Yes
Power
- Operating voltage: 5 V
- Input current: 2 A
- Power consumption (transmitter) (max): 650 mA
- Power consumption (receiver) (max): 650 mA
Operational conditions
- Operating temperature (T-T): 0 - 48 °C
- Operating relative humidity (H-H): 10 - 80%
Weight & dimensions
- Width: 85 mm
- Depth: 85 mm
- Height: 27 mm
- Weight: 490 g
- Receiver dimensions (WxDxH): 85 x 85 x 27 mm
- Transmitter dimensions (WxDxH): 85 x 85 x 27 mm
Packaging data
- Package width: 177 mm
- Package depth: 120 mm
- Package height: 308 mm
- Package weight: 1.35 kg
- Package type: Box
Packaging content
- Cables included: AC
- Quick start guide: Yes
Technical details
- Country of origin: Taiwan
Logistics data
- Master (outer) case width: 330 mm
- Master (outer) case length: 630 mm
- Master (outer) case height: 400 mm
- Master (outer) case gross weight: 14.5 kg
- Products per master (outer) case: 10 pc(s)
