LevelOne GEMINI 4-Channel PoE Network Video Recorder, 4 PoE Outputs, H.265

$288.51
$288.51 without VAT

LevelOne GEMINI 4-Channel PoE Network Video Recorder, 4 PoE Outputs, H.265.   More info

Brand: LEVELONE
SKU: 86116 PRC: 300670 EAN: 4015867202265 PN: NVR-0504

Description

Specifications

Performance

  • Video input channels: 4 channels
  • Maximum resolution: 3840 x 2160 pixels
  • Number of users: 32 user(s)
  • Video formats supported: H.264, H.265, MPEG4
  • Operating system installed: Embedded LINUX
  • Throughput data rate: 80 Mbit/s

Hard drive

  • HDD capacity: 0 GB
  • Number of HDDs supported: 1
  • Maximum storage capacity: 6 TB
  • HDD size: 3.5"

Ports & interfaces

  • Ethernet LAN (RJ-45) ports: 4
  • Power over Ethernet (PoE): Yes
  • Power over Ethernet (PoE) ports quantity: 4
  • HDMI output: Yes
  • HDMI ports quantity: 1
  • VGA (D-Sub) output ports: 1
  • USB 2.0 ports quantity: 2
  • Audio RCA inputs: 1
  • Audio RCA outputs: 1
  • Networking standards: IEEE 802.3at
  • Supported network protocols: TCP,UDP,IPv4,IPv6,Http,Https,SMTP,NTP,SNTP

Features

  • LED indicators: HDD, Power
  • On/off switch: Yes
  • Product colour: Black
  • Country of origin: China
  • Certification: CE, FCC, ISO9001, ISO14001

Power

  • Power consumption (typical): 65 W

System requirements

  • Mobile operating systems supported: Android, iOS
  • Browser supported: Internet Explorer 9+

Operational conditions

  • Operating temperature (T-T): -10 - 55 °C
  • Operating relative humidity (H-H): 10 - 90%

Technical details

  • Compliance certificates: RoHS

Weight & dimensions

  • Width: 240 mm
  • Depth: 48 mm
  • Height: 315 mm
  • Weight: 1 kg
  • Package width: 485 mm
  • Package depth: 290 mm
  • Package height: 85 mm
  • Package type: Box
  • Package weight: 1.15 kg

Packaging content

  • Cables included: AC
  • AC adapter included: Yes
  • CD manual: Yes

Logistics data

  • Master (outer) case width: 723 mm
  • Master (outer) case length: 503 mm
  • Master (outer) case height: 313 mm
  • Master (outer) case gross weight: 12.8 kg
  • Products per master (outer) case: 8 pc(s)
