Name: LevelOne 5m Antenna Cable, CFD-400, N Male Plug to N Male Plug, Indoor/Outdoor
Brand: LEVELONE
Price: 72 EUR
Availability: InStock

LevelOne 5m Antenna Cable, CFD-400, N Male Plug to N Male Plug, Indoor/Outdoor

72.00 €

59.50 € without VAT

Amount

Brand: LEVELONE

SKU: 120645 PRC: 504494 EAN: 4015867203965 PN: ANC-4150

Specifications

Features

Cable type: CFD400
Cable length: 5 m
Connector 1: No
Connector 2: No
Connector 1 gender: Male
Connector 2 gender: Male
Connector 1 form factor: Straight
Connector 2 form factor: Straight
Product colour: Black
Impedance: 50 Ω
Frequency band: 0 - 6 GHz
Jacket outer diameter: 1.03 cm
Jacket material: Polyvinyl chloride (PVC)
Conductor material: Copper
Conductor size: 2.74 mm
Insulation thickness: 2.2 mm
Load capacitance: 23.9 pF
Voltage Standing Wave Ratio (VSWR): 1.2 - 1.5

Operational conditions

Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%

Weight & dimensions

Width: 235 mm
Depth: 235 mm
Height: 50 mm

Packaging content

Quantity per pack: 1 pc(s)

Packaging data

Weight: 590 g
Package width: 300 mm
Package depth: 300 mm
Package height: 50 mm
Package weight: 607 g

Logistics data

Harmonized System (HS) code: 85442000
Master (outer) case width: 470 mm
Master (outer) case length: 335 mm
Master (outer) case height: 290 mm
Master (outer) case gross weight: 7 kg
Products per master (outer) case: 10 pc(s)
