Description
The LANBERG FP-LCUP-MS31-0020-TQ fibre optic cable is an OM3 multimode patch cord in turquoise with a 2 m cable, designed for data and InfiniBand links. It features LC connectors at both ends, both male, with UPC polishing and LC/UPC cable type. Its multimode fibre has a core diameter of 50 µm and a cladding diameter of 125 µm, with a round cable structure. The jacket is made of halogen-free material (LSZH), making it suitable for indoor building installations. As for optical performance, it offers an insertion loss of 0.2 dB and a return loss of 35 dB. It supports an operating temperature range of -40 - 85 °C, so it can be installed in demanding environments. Its bend radius of 7.5 mm allows it to be routed with ease in tight spaces.
Specifications
Features
- Cable length: 2 m
- Fibre optic type: OM3
- Cable shape: Round
- Connector 1: LC
- Connector 2: LC
- Connector 1 gender: Male
- Connector 2 gender: Male
- Connector polish type: UPC
- Cable type: LC/UPC
- Product colour: Turquoise
- Core diameter: 50 µm
- Cladding diameter: 125 µm
- Fiber mode structure: Multi-mode
- Insertion loss: 0.2 dB
- Return loss: 35 dB
- Jacket material: Low smoke zero halogen (LSZH)
Operational conditions
- Operating temperature (T-T): -40 - 85 °C
Weight & dimensions
- Cable diameter: 0.9 mm
- Bending radius: 7.5 mm
Packaging content
- Quantity per pack: 1 pc(s)
