Intel X710DA2BLK network card Internal Fiber 10000 Mbit/s

Intel X710DA2BLK network card Internal Fiber 10000 Mbit/s

Name: Intel X710DA2BLK network card Internal Fiber 10000 Mbit/s
Brand: INTEL
SKU: 207290
Price: 350.25 EUR
Availability: OutOfStock

More info

Brand: INTEL

350.25 €

Stock available: 0 units.

Unavailable

SKU: 80578 PRC: 207290 EAN: 5032037063456 PN: X710DA2BLK

Description

Internal Intel X710DA2BLK network card in black with green and stainless steel detailing, designed for fibre optic connections via two SFP+ ports and two RJ-45 Ethernet connectors. It offers a maximum transfer speed of 10000 Mbit/s, with support for 10GBASE-LR and 10GBASE-SR, and is compatible with speeds of 10 and 1000 Mbit/s. Its PCI Express 3.0 interface integrates into desktop computers, and it includes an Intel X710 controller, LED indicators, and quality of service to manage network traffic. It reaches up to 10 metres of operating distance and carries FCC A, UL, CE, VCCI, BSMI, CTICK, and KCC certifications.

Specifications

Ports & interfaces

Connectivity technology: Wired
Host interface: PCI Express
Interface: Fiber
Ethernet LAN (RJ-45) ports: 2
Fiber ports quantity: 2
Fiber optic connector: SFP+
PCI version: 3.0

Network

Maximum data transfer rate: 10000 Mbit/s
Ethernet LAN data rates: 10, 1000 Mbit/s
Fiber ethernet cabling technology: 10GBASE-LR, 10GBASE-SR
Quality of Service (QoS) support: Yes
Maximum operating distance: 10 m
LAN controller: Intel® X710

Design

Product colour: Black, Green, Stainless steel
Internal: Yes
LED indicators: Yes
Certification: FCC A, UL, CE, VCCI, BSMI, CTICK, KCC

System requirements

Compatible operating systems: https://www.intel.com/content/www/us/en/support/articles/000025890/network-and-i-o/ethernet-products.html

Operational conditions

Operating temperature (T-T): 0 - 55 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 0 - 90%

Weight & dimensions

Width: 167 mm
Depth: 69 mm

Packaging data

Quantity per pack: 1 pc(s)

Logistics data

Harmonized System (HS) code: 85176990

Other features

Data transfer rate: 8 GT/s
Cable type: SFP+ Direct Attached Twinaxial Cabling up to 10m
Market segment: Server
Target market: Artificial Intelligence, High Performance Computing
Intel Virtual Machine Device Queues (VMDq): Yes
PCI-SIG* SR-IOV Capable: Yes
On-chip QoS and Traffic Management: Yes
Intel Flexible Port Partitioning: Yes
Storage-over-ethernet: Yes
Speed & slot width: 8.0 GT/s, x8 Lane
Low halogen options available: No
Intelligent Offloads: Yes
iWARP/RDMA: No
Fiber Channel over Ethernet: No
Intel Ethernet Power Management: Yes
Intel Data Direct I/O Technology: Yes
Intel Virtualization Technology for Connectivity (VT-c): Yes
Interface type: PCIe v3.0 (8.0 GT/s)
Conflict-Free: Yes
Product type: Network Interface Card
Processor family: 700 Network Adapters (up to 40GbE)-700 Network Adapters (up to 40GbE)
Launch date: Q4'14
Ethernet adapter ARK ID: 83964
Export Control Classification Number (ECCN): 5A991
Storage Over Ethernet: iSCSI, NFS
Network interface card cable medium: Copper
Network interface card type: Server
Product brief URL: http://www.intel.com/content/dam/www/public/us/en/documents/product-briefs/ethernet-x710-brief.pdf
Status: Launched
Last change: 64826824
Commodity Classification Automated Tracking System (CCATS): NA
Controller type: Intel® Ethernet Controller X710
Cabling type: SFP+ Direct Attached Twinaxial Cabling up to 10m
Bracket height: Low-Profile (LP) / Full-Height (FH)
Product family: Intel 10 Gigabit server adapter
Product series: 700 Series Network Adapters (up to 40GbE)
Product codename: Fortville
