Description
The Intel EXPI9301CTBLK network card is an internal adapter with a PCI Express interface that incorporates an Ethernet RJ-45 port and the Intel 82574L controller, reaching a transfer speed of up to 1000 Mbit/s. Its connectivity is fully wired and offers a maximum range of 100 metres, with an energy consumption of only 1.9 W. This model includes a Low-Profile and Full-Height bracket, and is compatible with operating systems such as Windows 2000, XP, Vista, Server 2003, Server 2008, Linux and DOS. Certified according to FCC B, UL and CE standards, it operates in a temperature range of 0 to 55 °C and is stored between -40 and 70 °C, with dimensions of 55.3 mm in width, 119.2 mm in depth and 120 mm in height.
Specifications
Ports & interfaces
- Connectivity technology: Wired
- Host interface: PCI Express
- Ethernet LAN (RJ-45) ports: 1
- PCI version: 1.1
Network
- Maximum data transfer rate: 1000 Mbit/s
- Maximum operating distance: 100 m
- LAN controller: Intel® 82574L
Design
- Internal: Yes
- Certification: FCC B, UL, CE
Power
- Power consumption (typical): 1.9 W
System requirements
- Compatible operating systems: Windows 2000/XP/Vista/Server 2003/Server 2008, Linux, DOS
Operational conditions
- Operating temperature (T-T): 0 - 55 °C
- Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
- Width: 55.3 mm
- Depth: 119.2 mm
- Height: 120 mm
Logistics data
- Harmonized System (HS) code: 85176990
Other features
- Compliance industry standards: 802.3z
- Cable type: Category-5 up to 100m
- Market segment: Desktop
- Supported data transfer rates: 10/100/1000 Mbit/s
- Speed & slot width: 2.5 GT/s, x1 Lane
- Low halogen options available: No
- Interface type: PCIe v1.1 (2.5 GT/s)
- Product type: Network Interface Card
- Thermal Design Power (TDP): 1.9 W
- Processor family: Gigabit Ethernet Adapters (up to 2.5GbE)-Gigabit Ethernet Adapters (up to 2.5GbE)
- Ethernet adapter ARK ID: 50395
- Export Control Classification Number (ECCN): 5A991
- Commodity Classification Automated Tracking System (CCATS): NA
- Launch date: Q3'08
- Network interface card cable medium: Copper
- Network interface card type: Desktop
- Product brief URL: http://www.intel.com/Assets/PDF/prodbrief/319831.pdf
- Status: Launched
- Last change: 63903513
- Controller type: Intel 82574L
- Cabling type: Category-5 up to 100m
- Bracket height: Low-Profile (LP) / Full-Height (FH)
- Product family: Intel Gigabit desktop adapter
- Product series: Intel Gigabit CT
- Product codename: Shelter Island
