Processor


  • Processor manufacturer: Intel
  • Processor generation: 6th gen Intel® Core™ i5
  • Processor model: i5-6400
  • Processor base frequency: 2.7 GHz
  • Processor family: Intel® Core™ i5
  • Processor cores: 4
  • Processor socket: LGA 1151 (Socket H4)
  • Component for: PC
  • Processor lithography: 14 nm
  • Processor series: Intel Core i5-6400 Desktop series
  • Processor threads: 4
  • System bus rate: 8 GT/s
  • Processor operating modes: 64-bit
  • Processor boost frequency: 3.3 GHz
  • Processor cache type: Smart Cache
  • Thermal Design Power (TDP): 65 W
  • Package type: Box, Tray
  • Cooler included: No
  • Generation: 6th Generation
  • Stepping: R0
  • Bus type: DMI3
  • Memory bandwidth supported by processor (max): 34.1 GB/s
  • Processor codename: Skylake
  • Processor ARK ID: 88185

Memory


  • Maximum internal memory supported by processor: 64 GB
  • Memory types supported by processor: DDR4-SDRAM, DDR3L-SDRAM
  • Memory clock speeds supported by processor: 1333, 1600, 1866, 2133 MHz
  • Memory voltage supported by processor: 1.35 V
  • Memory channels: Dual-channel
  • ECC: No

Graphics


  • On-board graphics card: Yes
  • On-board graphics card model: Intel® HD Graphics 530
  • Maximum on-board graphics card memory: 64 GB
  • On-board graphics card outputs supported: Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI
  • On-board graphics card base frequency: 350 MHz
  • On-board graphics card dynamic frequency (max): 950 MHz
  • Number of displays supported (on-board graphics): 3
  • On-board graphics card 4K support: Yes
  • On-board graphics card DirectX version: 12.0
  • On-board graphics card OpenGL version: 4.5
  • On-board graphics card maximum resolution (DisplayPort): 4096 x 2304 pixels
  • On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 4096 x 2304 pixels
  • On-board graphics card maximum resolution (HDMI): 4096 x 2304 pixels
  • On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
  • On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 60 Hz
  • On-board graphics card refresh rate at maximum resolution (HDMI): 24 Hz
  • On-board graphics card ID: 0x1912

Features


  • PCI Express configurations: 1x16, 2x8, 1x8+2x4
  • Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0
  • Scalability: 1S
  • CPU configuration (max): 1
  • Embedded options available: No
  • Graphics & IMC lithography: 14 nm
  • Thermal solution specification: PCG 2015C
  • PCI Express CEM revision: 3.0
  • Export Control Classification Number (ECCN): 5A992C
  • Commodity Classification Automated Tracking System (CCATS): G077159
  • Execute Disable Bit: Yes
  • Idle States: Yes
  • Thermal Monitoring Technologies: Yes
  • Market segment: Desktop
  • Maximum number of PCI Express lanes: 16
  • PCI Express slots version: 3.0

Processor special features


  • Intel® Hyper Threading Technology (Intel® HT Technology): No
  • Intel® Identity Protection Technology (Intel® IPT): Yes
  • Intel® Turbo Boost Technology: 2.0
  • Intel® Quick Sync Video Technology: Yes
  • Intel® InTru™ 3D Technology: Yes
  • Intel® Wireless Display (Intel® WiDi): Yes
  • Intel® Clear Video HD Technology (Intel® CVT HD): Yes
  • Intel® Insider™: Yes
  • Intel® AES New Instructions (Intel® AES-NI): Yes
  • Enhanced Intel SpeedStep Technology: Yes
  • Intel Trusted Execution Technology: No
  • Intel® Memory Protection Extensions (Intel® MPX): Yes
  • Intel® Turbo Boost Technology 2.0 frequency: 3.3 GHz
  • Intel® Transactional Synchronization Extensions: No
  • Intel Enhanced Halt State: Yes
  • Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID): Yes
  • Intel VT-x with Extended Page Tables (EPT): Yes
  • Intel® Secure Key: Yes
  • Intel TSX-NI: No
  • Intel Stable Image Platform Program (SIPP): No
  • Intel® OS Guard: Yes
  • Intel Clear Video Technology: Yes
  • Intel Software Guard Extensions (Intel SGX): Yes
  • Intel 64: Yes
  • Intel Identity Protection Technology version: 1.00
  • Intel Secure Key Technology version: 1.00
  • Intel Small Business Advantage (SBA) version: 1.00
  • Intel Stable Image Platform Program (SIPP) version: 0.00
  • Intel Virtualization Technology (VT-x): Yes
  • Intel Virtualization Technology for Directed I/O (VT-d): Yes
  • Intel TSX-NI version: 0.00
  • Conflict-Free processor: Yes
  • Intel® Optane™ Memory Ready: No
  • Intel® Boot Guard: Yes
  • Intel® vPro™ Platform Eligibility: No

Operational conditions


  • Tcase: 71 °C

Technical details


  • Maximum resolution & refresh rate (VGA): N/A
  • Bus bandwidth: 8
  • Bus type units: GT/s
  • Launch date: Q3'15
  • Maximum resolution & refresh rate (DisplayPort): 4096x2304@60Hz
  • Maximum resolution & refresh rate (HDMI): 4096x2304@24Hz
  • Maximum resolution & refresh rate (Integrated Flat Panel): 4096x2304@60Hz
  • Product type: Processor
  • Number of graphics cores: 2
  • Supported memory types: DDR4-SDRAM, DDR3L-SDRAM
  • Status: Discontinued
  • Maximum memory: 64 GB
  • Processor brand name: Intel Core i5 Intel Core i5 Processor
  • Last change: 63903513
  • Maximum resolution (WiDi): 1080p
  • Product family: 6th Generation Intel Core i5 Processors
  • Bus speed: 8 GT/s
  • Maximum graphics card memory: 64 GB
  • Processor ID: 0x1912
  • Processor cache: 6144 KB

Logistics data


  • Harmonized System (HS) code: 8542310001

Weight & dimensions


  • Processor package size: 37.5 x 37.5 mm

Other features


  • Maximum internal memory: 65536 MB
  • Graphics output: eDP/DP/HDMI/DVI
  • Video decoding: Yes
