Description
Intel Core i5-14600K processor in box format, model from the i5-14xxx series with LGA 1700 socket and codename Raptor Lake, including 24 MB of Smart Cache. This 64-bit processor features 6 performance cores and 8 efficiency cores, with a turbo frequency of 5.3 GHz and a B0 stepping. Its base power is 125 W, reaching up to 181 W in maximum turbo mode, and it supports a memory bandwidth of up to 89.6 GB/s. It does not include a cooler in the package, and its 8 maximum DMI lanes facilitate connection with the platform.
Specifications
Processor
- Package type: Box
- Processor manufacturer: Intel
- Processor generation: Intel® Core™ i5 (14th gen)
- Processor model: i5-14600K
- Processor family: Intel® Core™ i5
- Processor cores: 14
- Processor socket: LGA 1700
- Processor threads: 20
- Processor operating modes: 64-bit
- Performance cores: 6
- Efficient cores: 8
- Processor boost frequency: 5.3 GHz
- Performance-core boost frequency: 5.3 GHz
- Performance-core base frequency: 3.5 GHz
- Efficient-core boost frequency: 4 GHz
- Efficient-core base frequency: 2.6 GHz
- Processor cache: 24 MB
- Processor cache type: Smart Cache
- Cooler included: No
- Processor base power: 125 W
- Maximum turbo power: 181 W
- Stepping: B0
- Maximum number of DMI lanes: 8
- Memory bandwidth supported by processor (max): 89.6 GB/s
- Processor codename: Raptor Lake
- Processor ARK ID: 236799
Memory
- Maximum internal memory supported by processor: 192 GB
- Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
- Memory channels: Dual-channel
- ECC: Yes
- Non-ECC: Yes
- Memory bandwidth (max): 89.6 GB/s
Graphics
- On-board graphics card: Yes
- Discrete graphics card: No
- On-board graphics card model: Intel UHD Graphics 770
- On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
- On-board graphics card base frequency: 300 MHz
- On-board graphics card dynamic frequency (max): 1550 MHz
- Number of displays supported (on-board graphics): 4
- On-board graphics card DirectX version: 12.0
- On-board graphics card OpenGL version: 4.5
- On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
- On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 5120 x 3200 pixels
- On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
- On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
- On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz
- On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
- On-board graphics card ID: 0xA780
- Discrete graphics card model: Not available
- Number of execution units: 32
- Multi-Format Codec Engines: 2
Features
- Export Control Classification Number (ECCN): 5A992C
- Commodity Classification Automated Tracking System (CCATS): 740.17B1
- Execute Disable Bit: Yes
- Idle States: Yes
- Thermal Monitoring Technologies: Yes
- Market segment: Desktop
- Use conditions: Workstation, PC/Client/Tablet
- Maximum number of PCI Express lanes: 20
- PCI Express slots version: 4.0, 5.0
- PCI Express configurations: 1x16+1x4, 2x8+1x4
- Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
- Scalability: 1S
- CPU configuration (max): 1
- Embedded options available: No
- Thermal solution specification: PCG 2020A
- Direct Media Interface (DMI) Revision: 4.0
Processor special features
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® Quick Sync Video Technology: Yes
- Intel® Clear Video HD Technology (Intel® CVT HD): Yes
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
- Intel® Speed Shift Technology: Yes
- Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
- Intel® Control-flow Enforcement Technology (CET): Yes
- Intel® Thread Director: Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
- Intel® Secure Key: Yes
- Intel® OS Guard: Yes
- Intel 64: Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel® Boot Guard: Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
- Intel® Volume Management Device (VMD): Yes
- Mode-based Execute Control (MBE): Yes
- Intel® Standard Manageability (ISM): Yes
Operational conditions
- Tjunction: 100 °C
Technical details
- OpenCL version: 3.0
- Launch date: Q4'23
- Status: Launched
Logistics data
- Harmonized System (HS) code: 8542310001
Weight & dimensions
- Processor package size: 45 x 37.5 mm
Other features
- L2 cache: 20480 KB
- Maximum internal memory: 192 GB
- Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
