Description
Specifications
Management features
- Switch type: Managed
- Switch layer: L2/L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
- Cloud-managed: Yes
- Configuring Location Settings (CLI): Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 48
- Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
- SFP module slots quantity: 4
- Console port: USB
- USB 2.0 ports quantity: 1
Network
- Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.
- 10G support: No
- Flow control support: Yes
Data transmission
- Switching capacity: 104 Gbit/s
- Throughput: 77.3 Mpps
- MAC address table: 8192 entries
- Latency (1 Gbps): 1.9 µs
- Static route: Yes
Security
- DHCP features: DHCP server, DHCP snooping, DHCP relay, DHCP client
- Access Control List (ACL): Yes
Multicast features
- Multicast support: Yes
Design
- Rack mounting: Yes
- Form factor: 1U
- Product colour: Black
Performance
- Built-in processor: Yes
- Processor manufacturer: ARM
- Processor model: ARM Cortex-A9
- Processor frequency: 1016 MHz
- Memory type: DDR3-SDRAM
- Internal memory: 4096 MB
- Flash memory: 16000 MB
Power
- Power source: AC
- AC input voltage: 200 - 240 V
- AC input frequency: 50/60 Hz
- Power consumption (max): 439 W
- Power consumption note: Max. Power (w/o PoE): 41.0W Max. Power (w/ PoE): 439W
Power over Ethernet (PoE)
- Power over Ethernet (PoE): Yes
- Power over Ethernet (PoE) ports quantity: 4
- Total Power over Ethernet (PoE) budget: 370 W
Other features
- Latency: 1 Gbps: 1.9 μSec
- Memory and processor: CPU: Dual-core Arm Cortex-A9 @ 1016 MHz Memory: 4 GB DDR3 Flash: 16 GB eMMC
- I/O ports: 48 x 10/100/1000BASE-T Class 4 PoE ports 4 x 1 G SFP ports Supports PoE Standards IEEE 802.3af, 802.3at 1 x USB-C console port 1
- Performance management: Management flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch
Operational conditions
- Operating temperature (T-T): 0 - 45 °C
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 5 - 95%
- Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
- Width: 442.5 mm
- Depth: 304.4 mm
- Height: 43.9 mm
- Weight: 4.39 kg
