Hewlett Packard Enterprise OfficeConnect 1950 12xGT 4SFP+ Managed network switch L3 10G Ethernet (100/1000/10000) 1U Grey
Hewlett Packard Enterprise OfficeConnect 1950 12xGT 4SFP+, Managed, L3, 10G Ethernet (100/1000/10000), Rack mounting, 1U.
More infoBrand: HEWLETT PACKARD ENTERPRISE
2,757,00 €Stock available: 0 units.
Unavailable
SKU:
77530
PRC:
138129
EAN:
889296308607
PN:
JH295A%23ABB
Description
Connect your network with the Hewlett Packard Enterprise OfficeConnect 1950 12xGT 4SFP+ managed switch, a grey L3 switch in 1U format measuring 440 x 44 x 160 mm and weighing 3.66 kg. It features twelve 10G Ethernet RJ-45 ports (100/1000/10000) and four SFP+ slots to expand the backbone link. Its RJ-45 console port facilitates configuration tasks, and web-based administration allows it to be managed from the browser. It offers Quality of Service (QoS) support, flow control, rate limiting, storm transmission control, port mirroring and Spanning Tree Protocol to maintain network stability. It includes a DHCP client and auto MDI/MDI-X, and complies with the IEEE 802.3, 802.3ab, 802.3ae and 802.3u standards.
Specifications
Management features
- Switch type: Managed
- Switch layer: L3
- Quality of Service (QoS) support: Yes
- Web-based management: Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity: 12
- Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
- SFP+ module slots quantity: 4
- Console port: RJ-45
- Copper ethernet cabling technology: 10BASE-T,10GBASE-T,100BASE-TX,1000BASE-T
Networking
- Networking standards: IEEE 802.3,IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3u
- Auto MDI/MDI-X: Yes
- Spanning tree protocol: Yes
- 10G support: Yes
- DHCP client: Yes
- Rate limiting: Yes
- Flow control support: Yes
- Port mirroring: Yes
- Broadcast storm control: Yes
Data transmission
- Switching capacity: 320 Gbit/s
- Throughput: 238 Mpps
- MAC address table: 16384 entries
- Latency (10-100 Mbps): 5 µs
- Latency (1 Gbps): 5 µs
- Latency (10 Gbps): 5 µs
- Jumbo frames support: Yes
Virtual LAN features
- VLAN support: Yes
Optical fiber
- Fiber optic connector: SFP+
- Fiber ethernet cabling technology: 10GBASE-R
Security
- Security algorithms: 802.1x RADIUS
- SSH/SSL support: Yes
- Access Control List (ACL): Yes
- IGMP snooping: Yes
Protocols
- Management protocols: SNMP, HTTPS, RMON1, FTP, IMC
Design
- Rack mounting: Yes
- Stackable: Yes
- Form factor: 1U
- Colour of product: Grey
- LED indicators: Yes
Performance
- Physical stacking (units): 2
- Built-in processor: Yes
- Processor frequency: 1.25 MHz
- Packet buffer memory: 2 MB
- Flash memory: 512 MB
- Internal memory: 1024 MB
Power
- Power consumption (typical): 34 W
- AC input voltage: 100-240
- AC input frequency: 50/60
Power over Ethernet (PoE)
- Power over Ethernet (PoE): No
Weight & dimensions
- Width: 440 mm
- Depth: 160 mm
- Height: 44 mm
- Weight: 3.66 kg
Packaging content
- Manual: Yes
- Cables included: AC
- Quick start guide: Yes
- Rack mount kit: Yes
- User guide: Yes
