Description
The Equip 650315 articulating wall mount is designed for televisions from 32 to 55 inches, with a maximum weight of 50 kg. Its mounting system supports 200 x 200, 300 x 300, 400 x 200 and 400 x 400 mm interfaces, so it fits a wide variety of screens. Once installed, it can be rotated up to 90 degrees to each side and the tilt adjusted between -20 and 10 degrees. The distance from the wall folds down to 6.2 cm when folded and extends up to 47.5 cm to position it. The housing is made of steel with a black finish, measuring 410 x 480 x 470 mm and weighing 4 kg. It includes screws and a quick installation guide.
Specifications
Mounting
- Maximum weight capacity: 50 kg
- Minimum screen size: 81.3 cm (32")
- Number of displays supported: 1
- Maximum screen size: 139.7 cm (55")
- Minimum VESA mount: 200 x 200 mm
- Maximum VESA mount: 400 x 400 mm
- Panel mounting interface: 200 x 200, 300 x 300, 400 x 200, 400 x 400
- Mounting type: Wall
Ergonomics
- Tilt angle range: -20 - 10°
- Swivel angle range: -90 - 90°
- Distance to the wall (max): 47.5 cm
- Distance to the wall (min): 6.2 cm
Design
- Product colour: Black
- Housing material: Steel
- Certification: CE
Packaging content
- Screws included: Yes
- Quick installation guide: Yes
Weight & dimensions
- Width: 410 mm
- Depth: 470 mm
- Height: 480 mm
- Weight: 4 kg
Packaging data
- Package width: 220 mm
- Package depth: 70 mm
- Package height: 520 mm
- Package weight: 4.3 kg
Logistics data
- Harmonized System (HS) code: 85299097
