Description
Connect your device to a wireless network with the Edimax N300 network card, a USB 2.0 adapter with a WLAN interface that adds Wi-Fi 4 (802.11n) connectivity in the single 2.4 GHz band. This model achieves a maximum transfer rate of 300 Mbit/s and features a 2x2 antenna for signal reception. It supports the 64-bit WEP, 128-bit WEP, WPA, and WPA2 security protocols, and uses a right-angle USB connector. Its design includes activity and link LED indicators, and it operates according to the IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n standards.
Specifications
Ports & interfaces
- Connectivity technology: Wired
- Host interface: USB
- Interface: WLAN
- USB connector form factor: Straight
- USB version: 2.0
Network
- Maximum data transfer rate: 300 Mbit/s
- Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
- Wi-Fi: Yes
- Wi-Fi band: Single-band (2.4 GHz)
- Frequency range: 2.4 - 2.4835 GHz
- Top Wi-Fi standard: Wi-Fi 4 (802.11n)
- Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)
- WLAN data transfer rates supported: 1, 2, 5.5, 6, 9, 11, 12, 24, 36, 48, 54, 144, 300 Mbit/s
- Security algorithms: 64-bit WEP, 128-bit WEP, WPA, WPA2
Design
- Component for: PC/Laptop
- Product colour: Black
- Internal: No
- Antenna: Yes
- Antenna design: Internal
- Antenna type: 2x2
- Transmitting power (CE): 1.5 dBm
- Transmitting power (FCC): 1.5 dBm
- Plug and Play: Yes
- LED indicators: Activity, Link
- Certification: CE, FCC, NCC, BSMI, RoHS
System requirements
- Windows operating systems supported: Yes
- Mac operating systems supported: Yes
- Linux operating systems supported: Yes
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 0 - 90%
- Storage relative humidity (H-H): 0 - 95%
Weight & dimensions
- Width: 16 mm
- Depth: 18.5 mm
- Height: 8 mm
- Weight: 4 g
Technical details
- Compliance certificates: CE, RoHS
Logistics data
- Harmonized System (HS) code: 85176990
