Return

Description

Specifications

Ports & interfaces


  • Connectivity technology: Wireless
  • Host interface: USB
  • Interface: WLAN / Bluetooth
  • USB version: 2.0

Network


  • Maximum data transfer rate: 150 Mbit/s
  • Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
  • Wi-Fi: Yes
  • Wi-Fi band: Single-band (2.4 GHz)
  • Top Wi-Fi standard: Wi-Fi 4 (802.11n)
  • Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)
  • WLAN data transfer rates supported: 1, 2, 5.5, 6, 9, 11, 12, 24, 36, 48, 54, 72, 150 Mbit/s
  • Security algorithms: 64-bit WEP, 128-bit WEP, 802.1x RADIUS, WPA, WPA2, WPS
  • Quality of Service (QoS) support: Yes
  • Bluetooth version: 4.0

Design


  • Product colour: Black
  • Internal: No
  • Antenna: Yes
  • Antenna design: Internal
  • LED indicators: Activity, Link
  • Receiver sensitivity: 11n(20MHz) MCS7: -64dBm±2dBm 11n(40MHz) MCS7: -64dBm±2dBm 11g 54Mbps: -65dBm±2dBm 11b 11Mbps: -79dBm±2dBm
  • Certification: CE, FCC, WiFi, BQB

Power


  • USB powered: Yes

System requirements


  • Windows operating systems supported: Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Ho
  • Mac operating systems supported: Yes
  • Linux operating systems supported: Yes

Operational conditions


  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 0 - 95%

Weight & dimensions


  • Width: 14.9 mm
  • Depth: 18.5 mm
  • Height: 7.1 mm
  • Weight: 3 g

Packaging data


  • Quantity per pack: 1 pc(s)

Logistics data


  • Harmonized System (HS) code: 85176990

Other features


  • Quick start guide: Yes
  • Transmit power range: 12 - 16 dBmW
