Description
The Dell WD22TB4 dock connects your laptop to the rest of your equipment via a Thunderbolt host interface and docking connection technology. It features two Thunderbolt 4 ports and one USB Type-C USB 3.2 Gen 2 port, as well as one Type-A USB 3.2 Gen 1 port for your usual peripherals. It adds two DisplayPort version 1.4 and one HDMI version 2.0, so you can set up several screens at once, and has a PowerShare USB port for charging devices. Network connection comes through an RJ-45 Ethernet port with transfer speeds of 10, 100 and 1000 Mbit/s. USB Type-C DisplayPort Alternate Mode allows video to be sent through the USB-C connector, and the DC power input plug powers the whole setup. It comes in black, weighing 650 g and measuring 205 x 29 x 90 mm (width x height x depth), a compact format that leaves free space on the desk.
Specifications
Ports & interfaces
- Connectivity technology: Docking
- Host interface: Thunderbolt
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- PowerShare: Yes
- Number of USB ports with PowerShare support: 1
- HDMI ports quantity: 1
- HDMI version: 2.0
- DisplayPorts quantity: 2
- DisplayPort version: 1.4
- Thunderbolt 4 ports quantity: 2
- Microphone in: No
- DC-in jack: Yes
- USB Type-C DisplayPort Alternate Mode: Yes
Network
- Ethernet LAN: Yes
- Ethernet LAN (RJ-45) ports: 1
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Performance
- Card reader integrated: No
- Maximum digital resolution: 5120 x 2880 pixels
- Product colour: Black
- LED indicators: Yes
Power
- Power source type: DC
- AC input voltage: 120 - 230 V
- AC input frequency: 50 - 60 Hz
- Power supply: 180 W
Software
- Windows operating systems supported: Windows 10, Windows 11
- Linux operating systems supported: Ubuntu 20.04 LTS
Weight & dimensions
- Width: 205 mm
- Depth: 90 mm
- Height: 29 mm
- Weight: 650 g
Packaging content
- Quick start guide: Yes
Logistics data
- Harmonized System (HS) code: 84733020
