Specifications

Management features


  • Switch type: Unmanaged
  • Switch layer: L2

Ports & interfaces


  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
  • Fast Ethernet (copper) ports quantity: 24
  • Combo SFP ports quantity: 1

Network


  • Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
  • 10G support: No
  • Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
  • Full duplex: Yes
  • Flow control support: Yes
  • Auto MDI/MDI-X: Yes
  • MAC address auto-learning supported: Yes
  • MAC address auto-aging supported: Yes
  • VLAN support: Yes

Data transmission


  • Switching capacity: 6.8 Gbit/s
  • Forwarding rate: 5.06 Mpps
  • MAC address table: 4000 entries
  • Store-and-forward: Yes

Design


  • Product colour: Black
  • Housing material: Metal
  • LED indicators: Yes

Power


  • AC input voltage: 100 - 240 V
  • AC input frequency: 50 - 60 Hz

Power over Ethernet (PoE)


  • Power over Ethernet (PoE): Yes
  • Power over Ethernet plus (PoE+) ports quantity: 24
  • Total Power over Ethernet (PoE) budget: 190 W

Operational conditions


  • Operating temperature (T-T): 0 - 45 °C
  • Storage temperature (T-T): -40 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%

Weight & dimensions


  • Width: 340 mm
  • Depth: 200 mm
  • Height: 43 mm
