Conceptronic DONN25G 15-in-1 DisplayLink USB 3.2 Gen 2 Docking Station, Triple 4K60Hz Display, HDMI x 2, DisplayPort, USB-C 10Gbps x 2, USB-A 10Gbps x 2, USB-A 5Gbps x 2, SD, TF/MicroSD, GbE, Audio, DC in, Security Slot, PD 3.0
More info
Brand: CONCEPTRONIC
299.88 €
247.84 €
without VAT
Stock available: 2 units.
Get it
on the
September 22
/
September 23
SKU:
107194
PRC:
536331
EAN:
4015867236611
PN:
DONN25G
Description
Connect your laptop to multiple peripherals with the Conceptronic DONN25G docking station and port replicator in silver, which connects wirelessly via USB 3.2 Gen 2 Type-C. This accessory features two HDMI 2.0 ports, one DisplayPort 1.2, two USB Type-A and two Type-C Gen 2 ports, plus one USB Type-C and another Type-A Gen 1, along with a 3.5 mm headphone jack and a combined microphone output. It supports USB power delivery with Power Delivery 3.0 up to 100 W, includes a DC input for external power, and offers Ethernet connectivity, all designed to expand your device's functionality. It has a total of two headphone outputs and a practical design for working with multiple screens and devices simultaneously.
Specifications
Ports & interfaces
- Connectivity technology: Wired
- Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
- USB Power Delivery (USB PD): Yes
- USB Power Delivery revision: 3.0
- USB Power Delivery up to: 100 W
- HDMI ports quantity: 2
- HDMI version: 2.0
- DisplayPorts quantity: 1
- DisplayPort version: 1.2
- Combo headphone/mic port: Yes
- Headphone outputs: 1
- Headphone connectivity: 3.5 mm
- DC-in jack: Yes
Network
- Ethernet LAN: Yes
- Ethernet LAN (RJ-45) ports: 1
- Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Performance
- Card reader integrated: Yes
- Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC
- HD type: 4K Ultra HD
- Maximum digital resolution: 4096 x 2160 pixels
- Maximum refresh rate: 60 Hz
- Cable lock slot: Yes
- Product colour: Silver
- On/off switch: Yes
- Housing material: Aluminium
- Country of origin: China
Power
- Power source type: DC
Software
- Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, W
- Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Ma
- Linux operating systems supported: Yes
- Mobile operating systems supported: Android 10.0, Android 11.0, Android 12.0, Android 13.0, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android
- Other operating systems supported: ChromeOS
Sustainability
- Sustainability compliance: Yes
Weight & dimensions
- Width: 100 mm
- Depth: 100 mm
- Height: 26.5 mm
- Weight: 380 g
Packaging data
- Package width: 211 mm
- Package depth: 166 mm
- Package height: 65.5 mm
- Package weight: 500 g
Packaging content
- Cables included: USB Type-C to USB Type-C
- AC adapter included: Yes
- Quick start guide: Yes
Technical details
- Pallet net height: 150 cm
- Pallet net length: 80 cm
- Pallet net width: 120 cm
- Compliance certificates: CE, RoHS
Logistics data
- Products per master (outer) case: 20 pc(s)
- Master (outer) case width: 380 mm
- Master (outer) case length: 450 mm
- Master (outer) case height: 380 mm
- Master (outer) case gross weight: 11 kg
- Products per shipping (inner) case: 20 pc(s)
- Harmonized System (HS) code: 8471800000
Other features
- Master (outer) cases per pallet: 24 pc(s)
