Description
The Axis 02370-001 Wi-Fi bridge/repeater network bridge in black mounts on a wall or shelf and operates as a wireless bridge, although it does not have Wi-Fi connectivity itself, as its connection technology is fully wired via Ethernet. This device has an RJ-45 port compatible with 10 and 100 Mbit/s networks, and conforms to IEEE 802.1x and IEEE 802.3at standards. It is powered by DC with an input voltage of 8 to 28 V or via PoE, with a maximum consumption of 4 W and a typical consumption of 1.85 W. It includes LED indicators for status monitoring and operates in a relative humidity range of 10 to 85%, supporting storage temperatures between -40 and 65 °C.
Specifications
Wireless LAN features
- Wi-Fi: No
Network
- Ethernet LAN: Yes
- Ethernet LAN data rates: 10, 100 Mbit/s
- Networking standards: IEEE 802.1x, IEEE 802.3at
- Cabling technology: 10/100Base-T(X)
Ports & interfaces
- Connectivity technology: Wired
- Ethernet LAN (RJ-45) ports: 1
- DC-in jack: Yes
Features
- Product type: Network bridge
- Mounting type: Shelf/wall-mounted
- Product colour: Black
- LED indicators: Yes
Power
- Power source type: DC, PoE
- DC input voltage: 8 - 28 V
- Power consumption (typical): 1.85 W
- Power consumption (max): 4 W
Operational conditions
- Operating temperature (T-T): -20 - 50 °C
- Operating relative humidity (H-H): 10 - 85%
- Storage temperature (T-T): -40 - 65 °C
- Storage relative humidity (H-H): 5 - 95%
Certificates
- Certification: CISPR 35, CISPR 32 Class B, EAC, EN 55035, EN 55032 Class B, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class B, ICES-3(B
Weight & dimensions
- Width: 128 mm
- Depth: 56 mm
- Height: 24 mm
- Weight: 107 g
Packaging content
- Quick installation guide: Yes
Other features
- Warranty period: 5 year(s)
Packaging data
- Quantity per pack: 1 pc(s)
