Description
Specifications
Performance
- Placement supported: Outdoor
- Connectivity technology: Wired
- PTZ modes: Digital PTZ
- Wide Dynamic Range (WDR): Yes
- Day/night mode: Yes
- Infrared (IR) cut-off filter: Yes
- Number of languages: 12
- Languages support: Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russia
- Certification: EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, I
- Type: IP security camera
Design
- Form factor: Dome
- Mounting type: Ceiling/wall
- Product colour: White
- Housing material: Polycarbonate (PC)
- International Protection (IP) code: IP66
- IK code: IK10
Camera
- Camera pan control: Yes
- Camera tilt control: Yes
- Minimum illumination: 0.13 lx
- Angle of rotation: 190°
- Tilt angle range: -10 - 80°
- Pan range: -190 - 190°
- Camera shutter speed: 1/33500 - 1/5 s
Image sensor
- Number of sensors: 1
- Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
- Progressive scan: Yes
- Sensor type: CMOS
Lens system
- Zoom capability: Yes
- Number of lenses: 1
- Focal length range: 3 - 8 mm
- Normal focusing range: 1 m
Night vision
- Night vision: Yes
- Night vision distance: 40 m
- LED type: IR
- Infra-red wavelength: 850 nm
Video
- Maximum resolution: 2592 x 1944 pixels
- Total megapixels: 5 MP
- Video compression formats: H.264, H.265, M-JPEG
- Video recording: Yes
- Frame rate: 30 fps
- Video streaming: Yes
- Gain control type: Auto
- Image quality adjustment: Brightness, Contrast, Saturation, Sharpness
- Flip & mirror: Yes
- Privacy masking: Yes
- Text caption overlay: Yes
- Bit rate control: Variable Bit Rate (VBR)
- Smart IR: Yes
Audio
- Audio detection: Yes
Network
- Ethernet LAN: Yes
- Networking standards: IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
- Supported network protocols: IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa , HTTP/2, TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour),
- Wi-Fi: No
- Bluetooth: No
- Quality of Service (QoS) support: Yes
Storage
- Built-in HDD: No
- Card reader integrated: Yes
- Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
- Flash memory: 8192 MB
- Internal memory: 2048 MB
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 1
- Terminal block port: Yes
Security
- Password protection: Yes
- Video motion detection: Yes
- Active tampering alarm: Yes
- IP address filtering: Yes
- HTTPS encryption: Yes
- Alert notification type: E-mail
Power
- Power source type: PoE
- Power consumption (typical): 6.4 W
- Power consumption (max): 12.1 W
Operational conditions
- Operating temperature (T-T): -40 - 50 °C
- Storage temperature (T-T): -40 - 65 °C
- Operating relative humidity (H-H): 10 - 100%
- Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
- Height: 107 mm
- Diameter: 14.9 cm
- Weight: 900 g
Packaging content
- Number of cameras: 1
- Drilling template included: Yes
- Manual: Yes
