Description
ASUS TUF GAMING B450-PLUS II, AMD, Socket AM4, AMD Ryzen 3000 Series, DDR4-SDRAM, 128 GB, DIMM
Specifications
Processor
- Processor manufacturer: AMD
- Processor socket: Socket AM4
- Compatible processor series: AMD Ryzen 3000 Series
- Maximum number of SMP processors: 1
Memory
- Memory channels: Dual-channel
- ECC сompatibility: ECC
- Supported memory clock speeds: 2133, 2400, 2666, 2800, 3000, 3200, 3400, 3466, 3533, 3600, 3733, 3866, 4000, 4400 MHz
- Maximum internal memory: 128 GB
- Unbuffered memory: Yes
- Supported memory types: DDR4-SDRAM
- Number of memory slots: 4
- Memory slots type: DIMM
Storage controllers
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA
- RAID levels: 0, 1, 10
Graphics
- Parallel processing technology support: CrossFireX
Internal I/O
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of SATA III connectors: 6
- Total number of SATA connectors: 6
- S/PDIF out connector: Yes
- Audio connector: Yes
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- Number of EATX power connectors: 1
- CPU fan connector: Yes
- Number of chassis fan connectors: 2
- Number of COM connectors: 1
- TPM connector: Yes
- RGB LED pin header: Yes
Rear panel I/O ports
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- HDMI ports quantity: 1
- HDMI version: 2.0b
- DisplayPorts quantity: 1
- DisplayPort version: 1.2
- USB connector type: USB Type-A, USB Type-C
Network
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- LAN controller: Realtek L8200A
- Wi-Fi: No
Features
- Motherboard chipset: AMD B450
- Audio chip: Realtek ALC S1200A
- Audio output channels: 8 channels
- Component for: PC
- Motherboard form factor: ATX
- Motherboard chipset family: AMD
- Cooling type: Active
- Power source type: ATX
- Number of mounting holes: 8
- Windows operating systems supported: Windows 10 x64, Windows 7 x64
Expansion slots
- PCI Express x1 (Gen 2.x) slots: 3
- PCI Express x16 (Gen 3.x) slots: 1
- Number of M.2 (M) slots: 1
BIOS
- BIOS type: UEFI AMI
- BIOS memory size: 256 Mbit
- Clear CMOS jumper: Yes
Logistics data
- Harmonized System (HS) code: 84733020
Weight & dimensions
- Width: 305 mm
- Depth: 244 mm
Packaging content
- Cables included: SATA
- Drivers included: Yes
