Zyxel WAC6303D-S 1300 Mbit/s White Power over Ethernet (PoE)

$208.53

$208.53 without VAT

Zyxel WAC6303D-S 1300 Mbit/s White Power over Ethernet (PoE). More info

Amount

Brand: ZYXEL

SKU: 80239 PRC: 200130 EAN: 4718937594603 PN: WAC6303D-S-EU0101F

Description

Specifications

Features

2.4 GHz: Yes
5 GHz: Yes
Maximum data transfer rate: 1300 Mbit/s
Wi-Fi data rate (max): 1300 Mbit/s
Ethernet LAN data rates: 10, 100, 1000 Mbit/s
Throughput data rate: 1600 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3au, IEEE 802.3az, IEEE 802.3u
Channel bandwidth: 80 MHz
MIMO: Yes
MIMO type: Multi User MIMO
Modulation: 16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DBQSK, QPSK
Wi-Fi Multimedia (WMM)/(WME): Yes
VLAN support: Yes
Maximal-Ratio Combining (MRC): Yes
Maximum Likelihood Detection (MLD): Yes
Cyclic Shift Diversity (CSD): Yes
Quality of Service (QoS) support: Yes
Receiver sensitivity: -103 dBm

Security

Security algorithms: 802.1x RADIUS, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA2-PSK
MAC address filtering: Yes
Number of SSID supported: 16

Protocols

DHCP client: Yes
Management protocols: SNMP v2c/v3

Ports & interfaces

Ethernet LAN (RJ-45) ports: 2
DC-in jack: Yes

Power

Power over Ethernet (PoE): Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Output voltage: 12 V
Output current: 2 A

Design

Placement: Ceiling, Wall
Product colour: White
Cable lock slot: Yes
Cable lock slot type: Kensington
Internal: No

Antenna

Antenna gain level (max): 4 dBi

Weight & dimensions

Width: 211 mm
Depth: 223 mm
Height: 39 mm
Weight: 800 g

Packaging data

Package width: 251 mm
Package depth: 247 mm
Package height: 55 mm
Package weight: 1.04 kg

Packaging content

Mounting kit: Yes

Operational conditions

Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -20 - 60 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 10 - 90%

Logistics data

Harmonized System (HS) code: 85176990
