Thermaltake Toughpower GF3 Snow 1200W - TT Premium Edition power supply unit 24-pin ATX ATX White
More info
Brand: THERMALTAKE
242.00 €Stock available: 0 units.
Unavailable
SKU:
102508
PRC:
460382
EAN:
4711475640290
PN:
ps-tpd-1200fnfage-n
Description
The Thermaltake Toughpower GF3 Snow 1200W TT Premium Edition is an ATX power supply unit rated at 1200 watts in a white finish, designed for builds seeking a clean and coherent look. With its fully modular cabling, you can connect only the necessary cables, including the 24-pin ATX connector and the 4+4-pin EPS, which simplifies internal management. It delivers a combined 1200 W on the +12 V rail with a maximum current of 100 A, along with protections against overcurrent, overvoltage, overheating, short circuit, and undervoltage to safeguard connected components. It also includes a floppy drive connector and a hold-up time of 17 ms, providing a stable and orderly foundation for demanding configurations.
Specifications
Power
- Total power: 1200 W
- Combined power (+3.3V): 130 W
- Combined power (+12V): 1200 W
- Combined power (+5V): 130 W
- Combined power (-12V): 3.6 W
- Combined power (+5Vsb): 15 W
- Max output current (+3.3V): 20 A
- Max output current (+12V): 100 A
- Max output current (+5V): 20 A
- Max output current (-12V): 0.3 A
- Max output current (+5Vsb): 3 A
- Hold time: 17 ms
- Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Ports & interfaces
- Motherboard power connector: 24-pin ATX
- Motherboard power cable length: 60 cm
- Number of SATA power connectors: 8
- SATA power cable length: 500, 650, 800, 950 mm
- Peripheral (Molex) power connectors (4-pin): 8
- Peripheral (Molex) power cable length: 500, 650, 800, 950 mm
- EPS power connector (4+4 pin): Yes
- PCI Express power connectors (6+2 pin): 4
- PCI Express power connectors (12+4 pin): 1
- CPU power connector (4+4 pin): Yes
- ATX Power connector (24-pin): Yes
- Floppy drive power connector: 1
- Floppy disk drive connector: Yes
- Floppy disk drive cable length: 15 cm
- Cabling type: Fully-Modular
Performance
- 80 PLUS certification: 80 PLUS Gold
- Purpose: PC
- Power supply unit (PSU) form factor: ATX
- ATX version: 3.0
Design
- Product colour: White
- Cooling type: Active
- Fan diameter: 14 cm
- Number of fans: 1 fan(s)
- Fan location: Top
- On/off switch: Yes
Operational conditions
- Operating temperature (T-T): 0 - 45 °C
- Storage temperature (T-T): -40 - 55 °C
- Operating relative humidity (H-H): 20 - 85%
- Storage relative humidity (H-H): 10 - 95%
Certificates
- Compliance certificates: BSMI, CB, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), cTUVus, UKCA
Weight & dimensions
- Width: 150 mm
- Depth: 160 mm
- Height: 86 mm
Logistics data
- Warranty period: 10 year(s)
