Description

Specifications

WAN connection


  • Ethernet WAN: Yes
  • DSL WAN: No
  • SIM card slot: Yes
  • 3G/4G USB modem compatibility: No
  • WAN connection type: RJ-45

Wireless LAN features


  • Wi-Fi band: Single-band (2.4 GHz)
  • Top Wi-Fi standard: Wi-Fi 4 (802.11n)
  • WLAN data transfer rate (max): 300 Mbit/s
  • Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network


  • Ethernet LAN: Yes
  • Ethernet LAN interface type: Fast Ethernet
  • Ethernet LAN data rates: 10, 100 Mbit/s
  • Cabling technology: 10/100Base-T(X)
  • Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Mobile network


  • Mobile network generation: 4G
  • 3G: Yes
  • 4G: Yes
  • 2G standards: GSM
  • 3G standards: WCDMA
  • 4G standard: LTE-TDD & LTE-FDD
  • Short Message Service (SMS): Yes

Ports & interfaces


  • Ethernet LAN (RJ-45) ports: 2
  • USB port: No
  • RJ-11 ports quantity: 1
  • Memory card slot(s): No
  • DC-in jack: Yes

Management features


  • Web-based management: Yes
  • Quality of Service (QoS) support: Yes
  • Reset button: Yes
  • WPS push button: Yes

Security


  • Security algorithms: WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
  • Firewall: Yes
  • Guest access: Yes
  • Schedule access: Yes

Protocols


  • DHCP client: No
  • DHCP server: Yes

Design


  • Product colour: White
  • Wall mountable: Yes
  • Indication light: Yes
  • LED indicators: LAN, LTE, Link, Power, WAN, WLAN
  • On/off switch: Yes
  • Product type: Tabletop router

Certificates


  • Compliance certificates: CE, RoHS

Packaging content


  • Cables included: LAN (RJ-45), Phone (RJ-11)
  • AC adapter included: Yes
  • Quick installation guide: Yes

Antenna


  • Antenna design: Internal & external
  • Antennas quantity: 4
  • Detachable antenna(s): Yes
  • Transmit power: 20 dBmW

Features


  • Built-in processor: Yes

Power


  • Power source type: AC, DC
  • AC input voltage: 100 - 240 V
  • AC input frequency: 50 - 60 Hz
  • Output voltage: 9 V
  • Output current: 1 A
  • External power adapter: Yes

Operational conditions


  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -30 - 70 °C
  • Operating relative humidity (H-H): 10 - 90%
  • Storage relative humidity (H-H): 5 - 90%

Weight & dimensions


  • Width: 126 mm
  • Depth: 69 mm
  • Height: 185 mm
  • Weight: 350 g

Logistics data


  • Harmonized System (HS) code: 85176990
