Description
The Synology DVA3221 network video recorder in black features 8 GB of DDR4 memory and supports up to 32 channels of video input in H.264, H.265 and MPEG4 formats, with PTZ control included. This unit has four SATA bays for 2.5 or 3.5-inch drives, supports RAID 0, 1, 5, 6, 10 and JBOD configurations, and offers a maximum storage capacity of 108 TB without drives included. Its connectivity includes a WAN Ethernet interface and a COM port, while it lacks WiFi and uses a single fan for cooling. Designed to manage up to 2048 users, the device offers multilingual support and is suitable for video surveillance installations requiring a high number of cameras.
Specifications
Performance
- Video input channels: 32 channels
- Internal memory: 8000 MB
- Internal memory type: DDR4
- Number of users: 2048 user(s)
- Video formats supported: H.264, H.265, MPEG4
- Languages support: Multi
- PTZ control: Yes
- Number of fans: 1 fan(s)
Wireless LAN features
- Wi-Fi: No
Hard drive
- HDD capacity: 0 GB
- Number of HDDs supported: 4
- Maximum storage capacity: 108 TB
- HDD interface: Serial ATA
- HDD size: 2.5/3.5"
- RAID support: Yes
- RAID levels: 0, 1, 5, 6, 10, JBOD
Ports & interfaces
- Ethernet LAN (RJ-45) ports: 4
- Ethernet LAN data rates: 1000 Mbit/s
- Ethernet WAN: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- eSATA ports quantity: 2
- eSATA: Yes
- COM ports quantity: 1
Features
- Brand compatibility: Synology
- LED indicators: Yes
- Reset button: Yes
- On/off switch: Yes
- Product colour: Black
Processor
- Built-in processor: Yes
- Processor cores: 4
- Processor frequency: 2.1 GHz
Display
- Built-in display: No
Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
System requirements
- Windows operating systems supported: Yes
- Mac compatibility: Yes
- Browser supported: Chrome, Firefox, Edge, Internet Explorer 10 onwards, Safari 10 onwards
Operational conditions
- Operating temperature (T-T): 0 - 40 °C
- Operating relative humidity (H-H): 5 - 95%
- Storage temperature (T-T): -20 - 60 °C
Weight & dimensions
- Width: 250 mm
- Depth: 237 mm
- Height: 166 mm
- Weight: 4.92 kg
Packaging content
- Cables included: AC, LAN (RJ-45)
Logistics data
- Harmonized System (HS) code: 85219000
