Description

StarTech.com 4K USB-C Dock, Triple UHD 4K Monitor Docking Station, Mac u0026 Windows, USB C to HDMI u0026 DisplayPort, 100W Power Delivery, 5x USB 5Gbps Hub - TAA, Wired, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, 100 W, 3.5 mm, 10,100,1000 Mbit/s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u

Specifications

Ports & interfaces


  • Connectivity technology: Wired
  • Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
  • USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
  • USB Power Delivery (USB PD): Yes
  • USB Power Delivery up to: 100 W
  • HDMI ports quantity: 1
  • DisplayPorts quantity: 2
  • Microphone in: Yes
  • Combo headphone/mic port: Yes
  • Headphone outputs: 2
  • Headphone connectivity: 3.5 mm
  • DC-in jack: Yes

Network


  • Ethernet LAN: Yes
  • Ethernet LAN (RJ-45) ports: 1
  • Ethernet LAN data rates: 10, 100, 1000 Mbit/s
  • Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
  • Auto MDI/MDI-X: Yes
  • Full duplex: Yes

Performance


  • Card reader integrated: No
  • Data transfer rate: 5 Gbit/s
  • Maximum digital resolution: 5120 x 2880 pixels
  • Cable lock slot: Yes
  • Product colour: Black, Silver
  • On/off switch: Yes
  • UASP support: Yes
  • Rubber feet: Yes
  • Housing material: Plastic
  • Certification: CE, FCC, TAA, REACH

Power


  • AC input voltage: 100 - 240 V
  • Input current: 2.5 A
  • Power supply: 100 W
  • Output voltage: 20 V
  • Output current: 7.5 A
  • Power plug type: Type N
  • Compatible power plug types: EU, UK

Software


  • Other operating systems supported: ChromeOS
  • Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, W
  • Mac compatibility: Yes
  • Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac O

Operational conditions


  • Operating temperature (T-T): 0 - 40 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 70%

Weight & dimensions


  • Width: 82 mm
  • Depth: 270 mm
  • Height: 34 mm
  • Weight: 382 g

Packaging data


  • Package width: 160 mm
  • Package depth: 320 mm
  • Package height: 80 mm
  • Package weight: 1.7 kg

Packaging content


  • Cables included: USB Type-C
  • AC adapter included: Yes
  • Manual: Yes

Technical details


  • Compliance certificates: RoHS

Logistics data


  • Products per master (outer) case: 8 pc(s)
  • Master (outer) case width: 365 mm
  • Master (outer) case length: 370 mm
  • Master (outer) case height: 370 mm
  • Harmonized System (HS) code: 84733020

Other features


  • Chipset: DisplayLink - DL-6950, Genesys Logic - GL3523, Genesys Logic - GL3523S, Texas Instruments - TPS65982, Parade Technologies - PS17
