StarTech.com 4 Port PCI Express (PCIe) SuperSpeed USB 3.0 Card Adapter w/ 2 Dedicated 5Gbps Channels - UASP - SATA / LP4 Power
More info
Brand: STARTECH.COM
68.60 €
56.69 €
without VAT
incl. 21 % VAT
Stock available: 5 units.
Get it
on the
October 14
/
October 15
SKU:
72826
PRC:
45061
EAN:
650308545972
PN:
PEXUSB3S42V
Description
The StarTech.com 4-port USB 3.2 Gen 1 PCI Express card adds four Type-A connections to your equipment via the PCIe host interface and the PCIe 2.0 expansion card standard, with a full-height and low-profile form factor that fits different chassis. It features a 4-pin Molex peripheral power connector and reaches a maximum data transfer rate of 5 Gbit/s thanks to its 2 x Renesas / NEC µPD720202 chipset. It has UASP and hot-swap support, supports cables up to 3 metres and carries CE and FCC certification. It operates within an operating temperature range of 0 to 50 °C and a relative humidity of 5 to 85%, and supports Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2 and Linux operating systems. Weighing 90 g and measuring 15 x 120 x 167 mm, it is installed inside the computer to expand its connectivity.
Specifications
Ports & interfaces
- Host interface: PCIe
- Output interface: USB 3.2 Gen 1 (3.1 Gen 1)
- Expansion card form factor: Full-height / Low-profile
- Expansion card standard: PCIe 2.0
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- Peripheral (Molex) power connectors (4-pin): 1
Design
- Internal: Yes
- Maximum cable length: 3 m
- Hot-swap: Yes
- Certification: CE, FCC
Features
- Chipset: 2 x Renesas / NEC - µPD720202
- Data transfer rate (max): 5 Gbit/s
- UASP support: Yes
Operational conditions
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -20 - 60 °C
- Operating relative humidity (H-H): 5 - 85%
System requirements
- Windows operating systems supported: Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Ho
- Linux operating systems supported: Yes
- Server operating systems supported: Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Technical details
- Compliance certificates: RoHS
Weight & dimensions
- Width: 15 mm
- Depth: 167 mm
- Height: 120 mm
- Weight: 90 g
Packaging data
- Drivers included: Yes
- Manual: Yes
- User guide: Yes
- Package width: 145 mm
- Package depth: 209 mm
- Package height: 39 mm
- Package weight: 200 g
Logistics data
- Harmonized System (HS) code: 84733020
