Ports & interfaces


  • Connectivity technology: Wired
  • Host interface: USB
  • Interface: Ethernet
  • Ethernet LAN (RJ-45) ports: 1
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity: 3
  • USB version: 3.2 Gen 1 (3.1 Gen 1)

Network


  • Maximum data transfer rate: 1000 Mbit/s
  • Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
  • Wake-on-LAN ready: Yes
  • Auto MDIX IEEE: Yes
  • Full duplex: Yes
  • Jumbo frames support: Yes
  • Auto-negotiation: Yes
  • Jumbo frames: 4000
  • VLAN tagging: Yes

Design


  • Product colour: Black
  • Internal: No
  • Chipset: Genesys Logic - GL3522, ASIX - AX88179
  • Hot-swap: Yes
  • Plug and Play: Yes
  • LED indicators: Activity, Link
  • Certification: CE, FCC, TAA

Power


  • Input current: 0.5 A
  • Output voltage: 5 V
  • Output current: 2 A
  • Power consumption (typical): 10 W

System requirements


  • Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, W
  • Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.6 Snow Leopar
  • Other operating systems supported: ChromeOS
  • Server operating systems supported: Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016

Operational conditions


  • Operating temperature (T-T): 0 - 50 °C
  • Storage temperature (T-T): -10 - 70 °C
  • Operating relative humidity (H-H): 0 - 85%

Weight & dimensions


  • Width: 45 mm
  • Depth: 87 mm
  • Height: 14 mm
  • Weight: 50 g

Packaging data


  • AC adapter included: Yes
  • Included power plug types: AU, EU, NA, UK
  • Package width: 152 mm
  • Package depth: 220 mm
  • Package height: 53 mm
  • Package weight: 340 g

Technical details


  • Compliance certificates: RoHS

Logistics data


  • Harmonized System (HS) code: 85176990
  • Master (outer) case width: 330 mm
  • Master (outer) case length: 455 mm
  • Master (outer) case height: 305 mm
  • Products per master (outer) case: 20 pc(s)

Other features


  • Housing material: Plastic
  • AC input voltage: 100-240 V
  • Flow control support: Yes
  • Cable length: 0.3 m
  • Power plug type: Type H
